Home > Products > New Products > KDN-300/150Y Air separation plant
KDN-300/150Y Air separation plant
- 0 per Month
- Shanghai Port
- T/T
Product Details
| Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | XAL |
| Model Number: | KDN-300/150Y | Production Rate: | 99.5-99.99% | Certification: | ISO9001:2008/CE/ASME |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1 WHY CHOOSE US
a. we have senior team
| Technical Title | Technical engineers | Senior engineers | Professional senior engineers |
| Quantity(individual) | 85 | 30 | 10 |
and exported to about 30 countries such as North America, Europe, Asia and Africa.
b. Using the air compressor to compress air at a needed point.
c. Using the pre-cooling system to cool the air with normal temperature makes the molecular sieve adsorbent in good condition.
d. After cooling by pre- cooling system.the air is putted into MS system to adsorb the water,CO2 and HC to extend life span of expander,heat exchanger in cold box.
e.Finally,the totally purified air be carrying into cold box to rectify,which separates oxygen and nitrogen product using the different boiling point.
air is compressed by compressor, which our company specially uses air booster compressor to increase efficiency. the follow is a picture of centrifugal air compressor of our company.
After compression and water separation.air into pre-cooling unit to pre cool.Our company specialized in using waste nitrogen pre cooling system.
c.Air purification system
air enter into the molecular sieve purify system to adsorb water,CO2 and HC,the adsorbers of our enterprise are all used double decker structure,which can adsorb impurity one hundred percent.
The purified water are putted into cold box to rectify,after expansion refrigerator distillation of air ,we can get the product of 99.6 %oxygen,and 99.99%nitrogen.
Plant model |
Oxygen capacity Nm3/h |
Oxygen purity % |
Nitrogen capacity Nm3/h |
Nitrogen purity PPmO2 |
| KDON-1000/1350 | GO2:1000 | 99.6 | GN2:1350 | ≤10PPmO2 |
| KDON-750/1400 | GO2:750 | 99.6 | GN2:1400 | ≤10PPmO2 |
| KDON-550/200 | GO2:550 | 99.6 | GN2:600 | ≤10PPmO2 |
| KDON-350/600 | GO2:350 | 99.6 | GN2:900 LN2:50L/h | ≤10PPmO2 |
| KDON-250/900(50Y) | GO2: 250 | 99.6 | GN2:900 LN2:50L/h | ≤3PPmO2 |
| KDON-170/100 | GO2:170 | 99.6 | GN2: 100/0.6MPa | ≤10PPmO2 |
| KDON-80/40 | GO2:80 | 99.6 | GN2: 40/0.6MPa | ≤10PPmO2 |
LOCATION
XAL was founded in 1992,which located at Development Zone, Xiangcheng District, Suzhou and is 80 kilometer far from SHANGHAI.
.We have 4 workshops,covering an area of 68000m2
Our plants are applied into many fields such as metallurgy, petrochemistry, coal gasification, electronics, chemistry engineering, photoelectricity, shipbuilding, medicine, construction, magnetic materials, textile, heat treatment and so on.......,and exported to about 30 countries such as North America, Europe, Asia and Africa.
| Year | Country | Quantity (Unit) |
| 2016 | India | 1 |
| 2015 | Italy | 1 |
| 2014 | Thailand | 2 |
| 2013 | Malaysia,Burma,Libya | 3(total) |
| 2012 | Thailand,Malaysia,Mexico India | 4(total) |
| 2011 | Iran,India,Vietam,Sri Lanka |
5(total)
|
We, devoting ourselves to the common development of air separation enterprises, will serve you more competitive products and realize common sustainable development with our leading technology and outstanding quality
You are always welcome to Suzhou to inquire about technical proposals, equipment selection advice and so on.
PLEASE CONTACT US:
PC: 215131
TEL: 86-512-65766331/65767253/65769056
FAX:86-512-65767057
Contact Us
- Suzhou Xinglu Air Separation Plant Science & Technology Development Co., Ltd.
- Contact nameAlex Xue
- Phone86-512-65769056
- Address989 Chengbo Road, Xiangcheng District, Suzhou City, Jiangsu Province. China Suzhou,Jiangsu
-
