Mpeg4 sd Digital Set Top Box

Name: Mpeg4 sd Digital Set Top Box
Brand: SHIDA
SKU: 134428537
Availability: InStock

US$ 1 - 20 MOQ: 100 Pieces

Key Specifications

Brand Name:

SHIDA

Model Number:

SDC-3000

Chengdu Star-Xinhui Tel-Communicational Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shengzheng

Delivery Detail:

Delivery time depends on order quantity.

Brand Name SHIDA

Model Number SDC-3000

Product Description

Features :

1 The device meets the DVB standard and supports English and Chinese interfacing as well as multi-condition receiving system,

2 PAL/NTSC auto switching, EPG pre-viewing.

3 Power- off memory function.

4 Contains the Locking functions, LED display.

5 Single voice channel, dual voice channel and stereo channels.

6 Contains a range of games and supports Loader technology.

7 On-line upgrade, on display of advertises and advertise menu.

8 Support broadcasting,email.

9 Support receiving Mosaic effect program.

10 Support 5 ways advertisement ( if choose to use ADS system)

11 Support 1000 channels memory

12 Subtitle available

13 Double AGC control

14 Built in OTP

15 Support MPEG1/2/4,H.264,AVS/AVS+

16 MIPS high speed CPU, main frequency to 400M

17 Support remote online upgrade

18 support AD system

19 Support VBI data input for WSS /Teletext/CC/VPS

Technical Specification

Item	Specs
Input frequency	110-862MHz
input Level	35dB-85dB
Input reflecting loss	>8dB
Input Resistance	75Ω
modulation	16QAM32QAM64QAM128QAM256QAM
symbol rate	0-9Mbauds
bandwidth	8MHz/7MHz/6MHz
Decoding mode	MPEG-I MPEG-2
Resolution	720×576(PAL)720×480(NTSC)
Picture output	1VP-P 75Ω
C/N	<26db 64QAM <33dB 256QAM
Flash	4 MByte
RAM	32MByte
CA	support
Audio decoding	MPEG-1-Audio LayerⅠ/Ⅱ MPEG-2-Audio/MPEG4-Audio /H.264-Audio Mono / stereo Support MP3,AC3,WMA,AAC,DTS audio format
Audio sampling rate	32,44.1,48KHz
PCR jitter adaptive capacity	>500ns,<-500ns
The channel switching time	< 2.5S
storable programs	1000
