quick 203H adjustable soldering station
- 3000 Set / Sets per Month
- Shenzhen
- Credit Card
- Multi-process Diesel Engine Driven Welder MD-550
- Sugon 8620 Dx Curved Nozzle Hot Air Gun Intelligent Lcd Micro Rework Soldering Station
- YAHANDA Fixture Eccentric locating plate for 3D/2D Welding Table
- YAHANDA Fixture Height rod for 3D/2D Welding Table
- Quadreat Bracket for 3D/2D Welding Table
- Hot sale Welding Table Accessories Height Adjustor
Product Details
Condition: | New | Place of Origin: | Guangdong, China | Brand Name: | ULUO |
Model Number: | UL-203H | Dimensions: | L150xW130xH105mm | Weight: | 4kg |
Usage: | lead free soldering | Certification: | CE Certification | After-sales Service Provided: | No overseas service provided |
Product Description
quick 203H adjustable soldering station:
1.High frequency current heating;Astonishing heating speed ; Only within 15s to reach 300℃ from room temperature.
2.Perfect intelligent soldering effects ; Sufficient power varies with the sizes of soldering point effectively avoids negative impact by cold soldering etc.
3.Extra-ordinary heat recovery ; Incredible temperature compensation speed can solve temperature problems occurring during the course of lead-free soldering. It is a must, may be a better tool for lead-free soldering and lower-temperature soldering.
4.Extension of life of soldering tips ; Relative lower temperature will largely prolong the life of soldering tips.
5.Auto sleeping & energy-efficient ; Temperature drops to 200℃ when not in use for over 20 minutes. When work is needed again, Temp., reaches up to the set temp., rapidly.
6.Temperature locking by password ; Stable soldering temperature ensures high soldering effects. Temperature can be locked by passwords to prevent inadvertent changes.
7.Separate design between heater and soldering tips ; Separate design of heater and tip makes the replacement easy so as to save expenditure and cost
Type | soldering station |
Model | UL-203H |
Power Supply | AC220V 50HZ/AC110V 60HZ |
Output Voltage | AC36V |
Set Temperature Range | 50~600°C |
No load Power | ≤6W |
Max Power | 90W |
Temperature Stability(no load) | ±2°C |
Tip to Ground Resistance | <2Ω |
Tip to Ground Potential | <2mV |
Outside Dimensions | (L)150*(W)130*(H)105mm |
Temperature Calibration Method | Digital Calibration |
Password-lock Mode | Yes |
Auto Sleeping Mode | Optional |
Heating Element | electromagnetic type |
Length of Handle Line | 1.5m |
Length of Power Line | 1.9m |
Weight | 4kg |
Outside Material | ESD Design,Aluminium material,stable usefull |
Note: All our soldering station can make as your requirements(110V/220V) Temperature test as the UL191 soldering iron tester
|
Warranty policy
One Years warranty
As usual, the shipping fee are high. if return China to repair are not worth the money. So we could support technology and give you the spare parts along with the product .
Note warranty does not cover wearing parts, for example heater element, soldering handle,soldering tips.
Packaging Detail: 1set/box
Shipping Detail: within 2 days after payment
Company Profile
Dongguan ULUO Electronic Co.Ltd Established in 2008,ULUO Electronic is one of the leading manufactures and exporters of soldering equipment.With over six years of development,take pride in a professional team of engineers,ULUO has grown to be a leading soldering station,soldering tips and soldering machine manufacture now.
Basic Information
Product/Service(We Sell): Soldering machine,soldering station,soldering tips,servo electric screwdriver.
Number of Employees: 50-100 people
Trade & Market
Main Markets: Africa,South America,North America,Southeast Asia,Eastern Asia,Mid East
Total Annual Sales Volume: US$10Million-US$50Million
Export Percentage: 30%-50%
Factory Information
Factory Size(ters): 300-800 Square meters
Factory Location: No.70 xida road shatou industrial zone chang'an town dongguan city guangdong province China
Number of R&D Staff: 5-10 people
Number of QC Staff: 5-10 people
Our soldering stations got CE Certificate:
Our soldering tips got SGS Certificate:
