Product Details
| Condition: | New | Place of Origin: | Guangdong, China | Brand Name: | ULUO |
| Model Number: | UL-390 | Dimensions: | L225xW100xH135mm | Weight: | 5.0kg, 5.0kg |
| Usage: | lead free soldering | Certification: | CE | After-sales Service Provided: | No overseas service provided |
Product Description
UL-390 self-feeder soldering station tin:
Power consumption | 90W |
Voltage | AC 220V/110V |
Temperature Range | 50°C-600°C |
Temperature Stability | ±2°C(stationary,no load) |
Tip to Ground Resistance | <2Ω |
Tip to Ground Potential | <2mV |
Motor | Step motor |
Feed speed | about 2.7mm/s-27mm/s(36º/s-360º/s) |
Feeding speed | 0-150mm |
Feeding interval time | 0-2.7s |
Backing time | 0-0.9s(about 0-25mm,constant speed 360º/s) |
Feeding mode | Auto(1-9) Manual(0) |
Diameter of solder wire | 0.3, 0.4, 0.5, 0.6, 0.8, 1.0,1.4, 1.6(mm) |
Weight | 5.0kg |
Features:
1.High frequency current heating,temperature controlled by K-type sensor,rapid temperature rising and thermal recovery.
2.Automatic soldering wire breaking,ESD safe design
3.Micro computer control,temperature adjusted by buttons,digital temperature calibration,auto sleeping function
4.Auto and manual feeding modes available.Feeding times can be set.
5.Feeding speed ,length and interval time can be adjusted,with adjustable backing function.
6.Pedal switch and hand switch available
7.Can be used as a lead free soldering only
8.Can prevent soldering wire from spattering during soldering process.
9.Soldering handle with plug-in heater element.
Below is the replaceable soldering tips for UL-390 self-feeder soldering station tin:
Custom Made and OEM
Contact us if you need to make special type soldering tips.we also undertake OEM orders.
How To Buy
1.Sample: Buyers can request samples before purchase,we offer them free of charge.
2.MOQ: 100pcs for soldering tips and 10pcs for soldering robot tips.
3.Delivery: We can deliver to any place around the world.
4.Lead time: 3 days for in stock models and 15 days for non-stock models.
