Specifications
220V 30W ceramic core heater:1.Excellent insulating
2.High efficiency thermal conductivity
3.Suitable for 936 solder statio
220V 30W ceramic core heater :
Features and Advantages:
(1)Long lifetime:airproof constructure for conquering the disintegration problem
(2)Quick temperature riseand Stable Temperaturescan be achieved--usefulness for every required heat setting
(3)Excellent insulating
(4)Energy efficientand high efficiency thermal conductivity—be able to generate heat internally and externally simultaneously.
(5)Small volumeand compact structure
(6)Equalized heat distributionandhigh power density.
(7)High cost performance
1 |
Part No. |
30W ceramic heater core |
2 |
Usage |
For 936 soldering station |
3 |
Working Voltage |
220V |
4 |
Heating Resistance |
3.0Ω±10%(23°C±2°C) |
5 |
Resistance of Feedback Line |
50Ω±10%(23°C±2°C) |
6 |
Dimension of product |
length:60mm, diameter:3.8mm |
7 |
Dimension of tail |
length:55.0±2.0mm, diameter:0.6mm |
