Specifications
Soldering fume extractor with single or double armd:1.Application:fume extractor in laser welding
2.Low noise.
Soldering fume extractor with single or double arms:
U1001,U1002 fume extractor:
Features:
1.Integrative structure design,easy installation,agile movement,no need to lay any pipelines.
2.Low noise.
3.Large-power brushless DC fan generates large air flow.
4.Triple filter design,remove hazardous substances from fume to ensure body safety.Pre-filter and main filter can be replaced separately to make full use of filters and cut down cost.
5.Built-in air cycling filtering system,avoid discharging the cool/hot air outside.
6.Both air flow and arms are adjustable.
Specifications:
Model |
U1001/U1002 |
Static pressure |
2000Pa |
System Flow |
235m³/h/2X150m³/h |
Filtering Efficiency |
0.3μm99.97% |
Power Consumption |
80W/200W |
Input Voltage |
AC110-220V |
Noise |
<55dB/<60dB |
Dimensions |
420(L)×245(W)×400(H)mm |
Quantity of Arms |
1/2 |
Weight |
12KG/13KG |
Below is the picture of arm for fume extractor:
this is the picture of triple filter for your reference:
Our factory main manufacture lead free soldering station and soldering tips.
and also make automatic soldering machine,automatic locking screw robot and smoke purification system.
Welcome to visit and inquiry!
