Help CenterFiber Optic Patch Cord SC,LC,ST
Related Products
-
SM SX SC APC-SC APC Fiber Optic Patch CordUS$ 0.5 - 5MOQ: 1 Piece -
Qualified MU Fiber Optic JumperUS$ 0.7 - 1MOQ: 1 Piece
-
Mode Conditioning Fiber Optic Patch CordUS$ 0.5 - 3MOQ: 5 Pieces
-
Fiber Optic OM3 OM4 LC Uniboot Patch CordUS$ 1 - 2MOQ: 1 Piece
-
Fiber Optic LC Uniboot Patch Cord With Pull-tabUS$ 2 - 3MOQ: 5 Pieces
Patch Cords are used to provide optical connection for fiber optic electronics. The use of the patch cord provides a quick and easy method for routing fiber patches in data centers, head-ends, cellular hubs and central offices. The patch cord can be used in an interconnect or cross-connect path connecting the incoming fibers to the electronic equipment and providing patching within the fiber paths. Patch Cords include simplex, duplex and Multi-fibers assemblies.
Optical Specification
Connector |
SC,FC,LC,ST,MU,E2000,MTRJ |
MPO/MTP |
|||
Polishing |
SM/UPC |
MM/PC |
SM/APC |
SM/PC |
MM/PC |
Insertion Loss(max) |
≤0.30dB |
≤0.30dB |
≤0.30dB |
≤0.75dB |
≤0.5dB |
Return Loss(min) |
≥50 dB |
≥35 dB |
≥60 dB |
≥40dB |
≥20dB |
Tensile Strength |
<10kg |
||||
Durability |
<0.20 dB typical change, 500 matings |
||||
Repeatability |
≤0.1dB |
||||
Storage , Operating Temperature [°C] |
-40~+85 |
||||
Geometric Specification
|
|
PC End-face |
APC End-face |
Radius of Curvature |
SC/FC/ST |
10~25 mm |
5~12 mm |
LC/MU |
7~25 mm |
5~15 mm |
|
Apex Offset |
≤50 um |
||
Fiber Spherical Height |
+/- 50 nm |
||
Angular Offset |
------ |
8°± 0.2° |
|
Features:
Meets Telcordia GR-326 Core and ROHS requirements.
The connector could be SC,FC,LC,ST,MU,E2000, MT-RJ etc.
The cable could be G652D,G655,G657,OM1,OM2,OM3 etc.
The cable size could be 1.2x2.5mm, 1,6x3.3mm, 2.0x4.1mm,2.8x5.7mm etc
Clean and Scratch-Free End Face
Proportional geometric test is applied to the normal production.
100% interferometer check is available under special requirement
Application:
Fiber CATV, Fiber Cabling system, LAN,FTTH
