Patch Cords are used to provide optical connection for fiber optic electronics. The use of the patch cord provides a quick and easy method for routing fiber patches in datacenters, head-ends, cellular hubs and central offices. The patch cord can be used in an interconnect or cross-connect path connecting the incoming fibers to the electronic equipment and providing patching within the fiber paths. Patch Cords include simplex, duplex and Multi-fibers assemblies.
Loopback Patch cord
- Ø Meets Telcordia GR-326 Core and ROHS requirements.
- Ø The connector could be SC, LC, and MTRJ etc.
- Ø The cable could be G652D, G655, G657, OM1, OM2, OM3, OM4 etc.
Optical Specification
Connector |
SC,FC,LC,ST,MU,E2000,MTRJ |
||
Polishing |
SM/UPC |
MM/PC |
SM/APC |
Insertion Loss(max) |
≤0.30dB |
≤0.30dB |
≤0.30dB |
Return Loss(min) |
≥50 dB |
≥35 dB |
≥60 dB |
Tensile Strength |
>70N |
||
Durability |
<0.20 dB typical change, 1000 matings |
||
Repeatability |
≤0.1dB |
||
Storage , Operating Temperature [°C] |
-40~+85 |
||
Geometric Specification (only for 3D interferometer tested)
Connector |
Connectors |
PC End-face |
APC End-face |
Radius of Curvature |
SC/FC/ST |
10~25 mm |
5~12 mm |
LC/MU |
7~25 mm |
5~15 mm |
|
Apex Offset |
≤50 um |
||
Fiber Spherical Height |
+/- 50 nm |
||
Angular Offset |
------ |
8°± 0.2° |
|
- Ø Clean and Scratch-Free End Face
- Ø Proportional geometric test is applied to the normal production.
- Ø 100% interferometer check is available under special requirement.
Length tolerance:
- Ø 0<L<1m, 0< *L<5cm
- Ø 1<L<10m, 0< *L<10cm
- Ø 10m<L, 0< *L< Lx1%(normal is 10cm)
L: Cable total length. *L: tolerance.
Packaging: Each loopback in a plastic bags,finally together in cartons.
Shipping: by air by DHL by FedEx or upon on requests.
