Product Details

Place of Origin:	Zhejiang, China	Brand Name:	LEFOO	Model Number:	LF10
Max. Current:	25A	Max. Voltage:	250VAC	Max. Working Pressure:	175PSI

Product Description

LF10 air compressor pressure switches / pressure control are used to regulate the tank pressure between two preset
values on small (up to 175PSI) electrically driven air compressors. They are available
with an unloader valve, which prevents compressors from starting under load,
and an auto-off disconnect lever for manual cut off the compressor. A four-port
manifold style is available which provides a means for easy mounting of valves
and gauges.

UL E228961 CSA220707 A030034

MODEL	Min ON (Cut-In)PSI	Max Off (Cut-Out) PSI	Differential PSI	Factory Setting PSI	Electrical Rating		Pipe Fittings	Contact Arrangement
MODEL	Min ON (Cut-In)PSI	Max Off (Cut-Out) PSI	Differential PSI	Factory Setting PSI	120VAC	240VAC	Pipe Fittings	Contact Arrangement
LF10-1H1	25	100	20-30	50-80	20A	12A	NPT 1/4 Male or Female NPT	NC
LF10-1H2	35	150	30-40	85-115	20A	12A	1/4" Male or Female NPT	NC
LF10-1H3	50	175	35-55	110-150	20A	12A	1/4" Male or Female NPT	NC

G1/4 (BSP 1/4) Male or Female Pipe Fittings are available.

Conversion: 1Kgf/cm2 = 14.2PSI , 1bar = 14.5PSI

MODEL	Min ON (Cut-In)PSI	Max Off (Cut-Out) PSI	Differential PSI	Factory Setting PSI	Electrical Rating		Pipe Fittings	Contact Arrangement
MODEL	Min ON (Cut-In)PSI	Max Off (Cut-Out) PSI	Differential PSI	Factory Setting PSI	120VAC	240VAC	Pipe Fittings	Contact Arrangement
LF10-4H1	25	100	20-30	50-80	20A	12A	1/4" Female NPT (4 Port)	NC
LF10-4H2	35	150	30-40	85-115	20A	12A	1/4" Female NPT (4 Port)	NC
LF10-4H3	50	175	35-55	110-150	20A	12A	1/4" Female NPT (4 Port)	NC
