Steel Container Water Blowing Machine

FOB Price

US$ 15,000 - 20,000 / Set

1 Set(Min. Order)

Port China Port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	yongheng
Model Number	Y98-200		After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Steel Container Water Blowing Machine

1.Suitable for:

Steel Container Water Blowing Machine is used for forming the part with complex surface.Can be used for the hydraulic bulging process of vacuum cup,thermos bottle,water bottle and other tableware and containers made of stainless steel,copper,aluminum,iron and other materials.

2.Main Feature:

1.Application:for forming the part with complex surface.

2.Speed control of the second section of moving beam;No-load rapid & slow copy deep drawing

3.Safety protection device should be equipped to provide security guarantee for the operators

4.Auto count function should be equipped

5.Locking-mould force and water pressure are adjustable

3.Main technical specification:

DESCRIPTION	UNIT	Y98-200
Nominal Capacity	KN	1000
Master Cylinder Stroke	MM	750
Nominal Capacity Of Pressurized Cylinder	KN	1000
Stroke Of Pressurized Cylinder	MM	350
Max. Capacity Of Injection Cylinder	L	7
Max. Injection Pressure Of Injection Cylinder	MPA	50
Max. Shut Height	MM	1300
Working Table Size	MM	650(L) x 650(W)
Sliding Platform Size	MM	550(L) x 450(W)
Downing Speed	MM/S	360
Pressing Speed	MM/S	30
Return Speed	MM/S	300
Motor Power	KW	15+2.2
Overall Size	MM	2200(L) x 1600(W) x 3750(H)

Product Description

Packaging & Shipping

Our Services

1.The special specifications can be custom made separately

2.Engineer is available to service oversea
