YDK-A 1000 H Frame Cold Extrusion Press Machine
1.Suitable for:
YDK-A 1000 H Frame Cold Extrusion Press Machine is suitable for the process of metal parts,praticularly in the cold extrusion and forging process of aluminum and aluminum alloy products.
2.Main Feature:
1.45 degree or 90 degree dctat guide,precision is reliable
2.Constant-power variable-capacity pump is used for supplying oil
3.Hole-arrangement type photo-electric safety device is adopted
4.Good air-proof performance
5.Good performance,steady and reliable.
3.Main technical specification:
DESCRIPTION | UNIT | YDK-A1000 |
Nominal Capacity | KN | 10000 |
Max. Work Pressure | MPA | 26 |
Max. Stroke | MM | 500 |
Height Of Max. Opening | MM | 1000 |
Height From Worktable To Floor | MM | 850 |
Working Table Size | MM | 1200(L) x 1350(W) |
Downing Speed | MM/S | 157 |
Pressing Speed | MM/S | 6.8-10 |
Return Speed | MM/S | ≥200 |
Size Of Machine | MM | 2300(L) x 2500(W) x 4100(H) |
Motor Power | KW | 75 |
1.The special specifications can be custom made separately
2.Enginner is available to service oversea
