16 Port 10/100Base Din-rail Managed Industrial Ethernet Switch Broadcom Program for Rail and Metro Automation

16 Port 10/100Base Din-rail Managed Industrial Ethernet Switch Broadcom Program for Rail and Metro Automation thumbnail-1
16 Port 10/100Base Din-rail Managed Industrial Ethernet Switch Broadcom Program for Rail and Metro Automation photo-1
US$ 100 - 499 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
InMax
Model Number:
i616A
Contact Supplier Request Quote Chat Now
Shenzhen InMax Technologies Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen HK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name InMax
Model Number i616A
InMax i616A 16 Potr Managed Industrial Ethernet Switch
Main Features
16x10/100BaseTX
InMax Ring Protocol “InMax Ring" (recovery time < 20ms) and RSTP/STP for network redundancy
SNMPv1/v2c/v3 for different levels of network management
Port-based VLAN, IEEE 802.1Q VLAN, and GVRP to ease network planning
IGMP snooping for filtering multicast traffic
Easy network management through web browser, CLI, Telnet /serial console, SNMP
Industrial-grade design with -40 to +75°C operating temperature and redundant power inputs
Metal, IP40 protection,DIN-Rail mounting, wall mounting

Overview
    The i616A series managed Industrial Ethernet switches are equipped with up to 16 Ethernet ports. Automatic alarm through E-mail, relay output. InMax Ring Protocol “InMax Ring" (recovery time < 20ms) and RSTP/STP for network redundancy. RSTP/STP can increase system reliability and your network availability. Industrial-grade design with -40 to +75°C operating temperature and redundant power inputs. The super hardware reliability is especially suitable for industrial applications.

Features and Benefits
Easy network management through web browser, CLI, Telnet /serial console, SNMP
InMax Ring Protocol InMax Ring" (recovery time < 20ms) and RSTP/STP for network redundancy
IGMP snooping for filtering multicast traffic
Port-based VLAN, IEEE 802.1Q VLAN, and GVRP to ease network planning
QoS and ToS/DiffServ to increase determinism
Port Trunk for optimum bandwidth utilization
RADIUS, TACACS+, SNMPv3, IEEE 802.1X, HTTPS and SSH
SNMPv1/v2c/v3 for different levels of network management
RMON for efficient network monitoring and proactive capability
Bandwidth management prevents unpredictable network status
Lock port function for blocking unauthorized access based on MAC address
Automatic alarm through e-mail, relay output

Specifications
Standards IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.1D-2004 for STP
IEEE 802.1w for Rapid STP
IEEE 802.1Q for VLAN Tagging
IEEE 802.1p for Class of Service
IEEE 802.1X for Authentication
IEEE 802.3ad for Port Trunk with LACP
IEEE 802.3x for Flow Control
Protocols IGMPv1/v2, GVRP, SNMPv1/v2c/v3, DHCP Client,
TFTP, SMTP, RMON, HTTP, HTTPS, Telnet, Syslog,
SSH, SNMP Inform, LLDP, SNTP Server/Client
MIB MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, Q-BRIDGE MIB,
Bridge MIB, RSTP MIB, RMON MIB Group 1, 2, 3, 9
Flow Control IEEE 802.3x flow control, back pressure flow control

Switch Properties
Priority Queues 4
Max Number of Available VLANs 256
VLAN ID Range VID 1 to 4094
IGMP Groups 256
MAC Table Size 8K
Packet Buffer Size 1 Mbit

Interface
Fiber Ports 10/100BaseTX auto negotiation
RJ45 Ports 10/100BaseTX auto negotiation
Console Port RS-232 (RJ45 connector)
Alarm Contact 2 relay outputs with current carrying capacity of 1A@24V

LED
System Led SYS
Port Led Copper: Link 1~16, Act 1~16 ,
Power Led PWR

Power Requirements
Input Voltage 24VDC (12 ~ 36VDC), redundant dual inputs
Input Current InMax. <0.24A@24VDC,<6W
Overload Current
Protection		 Present
Reverse Polarity
Protection		 Present
Connector 6-contact terminal blocks

Mechanical Properties
Housing Metal, IP40 protection
Dimensions 60.2 x 112.5 x 138.5 mm
Weight 750g
Installation DIN-Rail mounting, wall mounting

Environmental Limits
Operating Temperature
Standard Models     0  to  +60°C (32 to 140°F )
Wide Temp. Models   -40 to  +75°C (-40 to 167°F)
Storage Temperature   -40  to  +85°C (-40 to 185°F )
Ambient Relative
Humidity		 5 to 95% (non-condensing)

Standards and Certifications
Safety UL 60950-1
EMI FCC Part 15 Subpart B Class A, EN 55022 Class A
EMS EN 61000-4-2 (ESD) Level 4
EN 61000-4-3 (RS) Level 3
EN 61000-4-4 (EFT) Level 4
EN 61000-4-5 (Surge) Level 4
EN 61000-4-6 (CS) Level 3
EN 61000-4-8 Level 5
Shock IEC 60068-2-27
Freefall IEC 60068-2-32
Vibration IEC 60068-2-6

Warranty
Warranty Period 5 years

Ordering Information
Available Models Transceiver Type Connector Type Temperature Range
i616A 10/100BaseTX  RJ45  -40°C to +85°C
(-40 to 185°F )

Dimensions

 16 Port 10/100Base Din-rail Managed Industrial Ethernet Switch Broadcom program for Rail and Metro Automation
