12 Port Managed Industrial Ethernet Switches With 8+4G, I612A

12 Port Managed Industrial Ethernet Switches With 8+4G, I612A thumbnail-1
12 Port Managed Industrial Ethernet Switches With 8+4G, I612A photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
InMax
Model Number:
i612A
Contact Supplier Request Quote Chat Now
Shenzhen InMax Technologies Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen HK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name InMax
Model Number i612A

InMax i612A 8+4G Managed Industrial Ethernet Switches



Main Features

Ø 8x10/100Base+4x1000BaseX

Ø InMax Ring Protocol “InMax Ring" (recovery time < 20ms) and

   RSTP/STP for network redundancy

Ø SNMPv1/v2c/v3 for different levels of network management

Ø Port-based VLAN, IEEE 802.1Q VLAN, and GVRP to ease

   network planning

Ø IGMP snooping for filtering multicast traffic

Ø Easy network management through web browser, CLI,

   Telnet /serial console, SNMP

Ø Industrial-grade design with -40 to +75°C operating

   temperature and redundant power inputs

Ø Metal, IP40 protection,DIN-Rail mounting, wall mounting



Overview

The i612A series managed Industrial Ethernet switches are equipped with up to 8 Ethernet ports. Automatic alarm through E-mail, relay output. InMax Ring Protocol “InMax Ring" (recovery time < 20ms) and RSTP/STP

for network redundancy. RSTP/STP can increase system reliability and your network availability. Industrial-grade design with -40 to +75°C operating temperature and redundant power inputs. The super hardware reliability is especially suitable for industrial applications.



Features and Benefits

Easy network management through web browser, CLI, Telnet /serial console, SNMP

InMax Ring Protocol InMax Ring" (recovery time < 20ms) and RSTP/STP for network redundancy

IGMP snooping for filtering multicast traffic

Port-based VLAN, IEEE 802.1Q VLAN, and GVRP to ease network planning

QoS and ToS/DiffServ to increase determinism

Port Trunk for optimum bandwidth utilization

RADIUS, TACACS+, SNMPv3, IEEE 802.1X, HTTPS and SSH

SNMPv1/v2c/v3 for different levels of network management

RMON for efficient network monitoring and proactive capability

Bandwidth management prevents unpredictable network status

Lock port function for blocking unauthorized access based on MAC address

Automatic alarm through e-mail, relay output

Specifications

Standards:

IEEE 802.3

IEEE 802.3u

IEEE 802.3ab

IEEE 802.1D-2004 for STP

IEEE 802.1w for Rapid STP

IEEE 802.1Q for VLAN Tagging

IEEE 802.1p for Class of Service

IEEE 802.1X for Authentication

IEEE 802.3ad for Port Trunk with LACP

IEEE 802.3x for Flow Control



Protocols:

IGMPv1/v2, GVRP, SNMPv1/v2c/v3, DHCP Client,

TFTP, SMTP, RMON, HTTP, HTTPS, Telnet, Syslog,

SSH, SNMP Inform, LLDP, SNTP Server/Client



MIB:

MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, Q-BRIDGE MIB,

Bridge MIB, RSTP MIB, RMON MIB Group 1, 2, 3, 9



Flow Control:

IEEE 802.3x flow control, back pressure flow control



Switch Properties:

Priority Queues: 4

Max. Number of Available VLANs: 256

VLAN ID Range:  VID 1 to 4094

IGMP Groups: 256

MAC Table Size: 8K

Packet Buffer Size: 1 Mbit



Interface:

Fiber Ports:  1000Base-X (SFP slot)

RJ45 Ports: 10/100BaseTX auto negotiation

Console Port: RS-232(RJ45 connector)

Alarm Contact: 2 relay outputs with current carrying capacity of 1A@24V



LED:

System Led:SYS

Port Led:Copper: Link1~8, Act1~8

              Fiber: Link/ Act G1,G2,G3,G4

Power Led:PWR



Power Requirements:

Input Voltage: 24VDC (12 ~ 36VDC), redundant dual inputs

Input Current: MAX. <0.66A@24VDC,<16W

Overload Current Protection: Present

Reverse Polarity Protection: Present

Connector: 6-contact terminal blocks



Mechanical Properties:

Housing: Metal, IP40 protection

Dimensions: 60.2 x 112.5 x 138.5 mm

Weight: 750g

Installation: DIN-Rail mounting, wall mounting



Environmental Limits:

Operating Temperature:

Standard Models: 0 to +60°C (32 ~ 140°F )

Wide Temp. Models:-40 to +75°C (-40 to 167°F)

Storage Temperature: -40 to +85°C (-40 to 185°F )

Ambient Relative Humidity: 5 to 95% (non-condensing)



Standards and Certifications:

Safety: UL 60950-1

EMI: FCC Part 15 Subpart B Class A, EN 55022 Class A

EMS:

EN 61000-4-2 (ESD) Level 3, EN 61000-4-3 (RS) Level 3,

EN 61000-4-4 (EFT) Level 3, EN 61000-4-5 (Surge) Level 3,

EN 61000-4-6 (CS) Level 3, EN 61000-4-8 Level 3

Shock:  IEC 60068-2-27

Freefall:  IEC 60068-2-32

Vibration:  IEC 60068-2-6

Warranty Period: 5 years



Dimensions

 12 port Managed Industrial Ethernet Switches with 8+4G, i612A
