Specifications
1.Type: BTO-10/12/18/22/28/30/60/652.Core wire diameter: 2.5mm
3.Coil diameter:450mm-980mm
4. stainless steel sheet or gi
RAZOR BARB IRON WIRE OR CONCERTINA WIRE WITH BATB
MATERIAL: galvanized steel sheet or stainless steel sheet
Razor barbed iron wire or concertina barb wire is a new type protective fence. It features with the elegant appearance, affordable price, effective protection and easy to installment. This product mainly use in the areas as the mining industry, apartments and gardens, frontier sentry, prison etc,.
Process production: Stamping the hot dipped galvanized steel sheet or stainless steel sheet into the blade shape then combining with the core wire, because of the unique designation it is difficult to touch or climb. The razor barb iron wire can protect the property very well.
| type | blade thichness | core wire diameter | blade length | blade width | razor spacing |
| BTO-10 | 0.5±0.05 | 2.5±0.1 | 10±1 | 13±1 | 26±1 |
| BTO-12 | 0.5±0.05 | 2.5±0.1 | 12±1 | 13±1 | 26±1 |
| BTO-18 | 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 33±1 |
| BTO-22 | 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 37±1 |
| BTO-28 | 0.5±0.05 | 2.5±0.1 | 28±1 | 15±1 | 45±1 |
| BTO-30 | 0.5±0.05 | 2.5±0.1 | 30±1 | 18±1 | 45±1 |
| BTO-60 | 0.5±0.05 | 2.5±0.1 | 60±2 | 32±1 | 100±2 |
| BTO-65 | 0.5±0.05 | 2.5±0.1 | 65±2 | 21±1 | 100±2 |
Features: corrosion resistant, aging resistant,Resist the ultraviolet (uv) and weather proof.
| roll diameter (mm) | rolls number | standard length | type | notes |
| 450 | 33 | 7-8m | CBT-60.65 | Single coil |
| 500 | 56 | 12-13m | CBT-60.65 | Single coil |
| 700 | 56 | 13-14m | CBT-60.65 | Single coil |
| 960 | 56 | 14-15m | CBT-60.65 | Single coil |
| 450 | 56 | 8-9m (3 clips) | BTO-10.12.18.22.28.30 | cross type |
| 500 | 56 | 9-10m (3 clips) | BTO-10.12.18.22.28.30 | cross type |
| 600 | 56 | 10-11m(3 clips) | BTO-10.12.18.22.28.30 | cross type |
| 600 | 56 | 8-10m(5 clips) | BTO-10.12.18.22.28.30 | cross type |
| 700 | 56 | 10-12m(5 clips) | BTO-10.12.18.22.28.30 | cross type |
| 800 | 56 | 11-13m(5 clips) | BTO-10.12.18.22.28.30 | cross type |
| 900 | 56 | 12-14m(5 clips) | BTO-10.12.18.22.28.30 | cross type |
| 960 | 56 | 13-15m(5 clips) | BTO-10.12.18.22.28.30 | cross type |
| 980 | 56 | 14-16m (5 clips) | BTO-10.12.18.22.28.30 | cross type |
Category: Concertina barb wire, linear type razor wire, flat plate razor wire.
Stamping the hot dipped galvanized steel sheet or stainless steel sheet into the blade shape then combining with the core wire, because of the unique designation it is difficult to touch or climb. The razor barb iron wire can protect the property very well.
