Specifications
1.10.1''TFT-LCD(digital) Driver Board2. Use for display equipment
3. Input signal: CVBS
4. datasheet: yes
1) Product Name: 10.1''TFT-LCD(digital) Driver Board
2) Product number: Silicon-P-007
3) Backlight: LED
4) Resolution: 800x(RGB)×480
5) View Angle(up/down/left/right): 100/130
6) Brightness >300Cd/m2
7) Input Signal: CVBS
8) System Format: PAL/NTSC(Auto switch)
9) Supply Voltage: 6V-12V
10) Rated power: 3.5W
11) Adjust model: Menu adjust
12) PCB Structural dimension(mm): 66(W)×69.8(H)×7(D)
13) Screen Size(mm): 235(W)×145.9(H)×5.0(D)
14) Operating Temperature: -20~60 °C
15) Relative Humidity :5~95% RH
16) Storage Temperature: -40~+70°C
17) Customize: Free for LOGO, accept the CABLE lines
18) Packing: 60pcs/Box
