Help CenterAuto Laptop Repair BGA Equipment (PS400)
Related Products
-
Weller BGA Rework Station/BGA Rewok Machine(PS400)NegotiableMOQ: 1 Set -
Motherboard BGA Repair Machine With Two Camera SV550ANegotiableMOQ: 1 Set
-
PS400 Soldering Station for Small Motherboard Bga RepairUS$ 12,000 - 18,000MOQ: 1 Set
-
New Model SV560 High Vision System BGA Rework Station With Auto Profile FunctionNegotiableMOQ: 1 Set
-
Auto Profile!SV550A BGA Repair Station for All Kinds of Chips and Motherboard (RW-SV550A)NegotiableMOQ: 1 Piece
Specifications
full automatic BGA Equipmentpatented tech
3 heaters,mix IR & hot air heating,775,478/479 socket,XBOX360,PS2/3 laptop
Fully-automatic BGA Equipment
Specification
PCB dimension: W20×20~W350×350mm
PCB thinkness: 0~4mm
BGA dimension: 1mm×1mm~70mm×70mm
Working table adjustment: ±10MM forward/backward,±10MM left/right
Lower hot-air heater: 800W
Upper hot-air heater: 800W
Bottom preheatfar infrared: 2700W
Temperatur control: K-type thermocoupleclose cycle controlled
PCB locating way: Outer or Jig
Power supply: single-phase 220V,50/60Hz,4.5KW
Machine dimension: L600×W600×H750mm
Weight: Appox. 85Kgs
-----------------------------------------------------------------------------------------------------------------------------
Description
* The streamline design is gorgeous and room-saving.
* Hot air head and mounting head are designed 2 in 1, and have both the auto soldering and
mounting function.
* Upper/lower hot-air heating,bottom infrared,three independent heating areas, temperature
and time can be displayed digitally on the touch screen.
* Powerful cross flow fans cool the bottom heating zone rapidly and constantly.
* Color optical system with functions of spilt vision, zoom-in and micro-adjust, equipped with
aberration detection device; with auto focus and software operation function, 22X optical
zoom.
* Embeded industrial computer can ananlyze the two proctically-tested profiles, and compare them with the history saved profiles;profile saving no limit for the industrial computer
* Color LCD monitor, touch screen interface;
* Built-in vacuum pump;60 rotating in φ angle mounting nozzle is micro-adjustable.
* 8 segments of temperature up(down) and 8 segments constant temperature control, profile saving is unlimited in the industrial computer;
* Suction nozzle can identify material and mounting height automatically, and can control the
air pressure within a small range.
* Equipped with different hot air nozzles, easy to replace and able to locate in any angle.
* Big size splint, equipped with deformation-proof supporting device,suitable for the accurate
rework of all kinds of PCB.
* Can handle 775 socket, 478 socket,XBOX360, PS2/3, PSP,etc .
