Linyi jinhu color coating aluminum industry co.,Ltd
Types of tile:
1).Classical Tile,
| Model No. | Zj01 | Zj02 |
| Tile size | 1400mm*420mm | 1340mm*420mm |
| Installed Exposure | 1350mm*370mm | 1290mm*370mm |
| Tiles per Sqm | 2sheets | 2.08Sheets |
| Installed Weight | 3.0kg/Sheet | 2.8kg/Sheet |
| Quantity in 20FCL | 9000PCS | 9500PCS |
2).Modern Classical Tile,
| Model No. | Zj01 | Zj02 |
| Tile size | 1400mm*420mm | 1340mm*420mm |
| Installed Exposure | 1350mm*370mm | 1290mm*370mm |
| Tiles per Sqm | 2sheets | 2.08Sheets |
| Installed Weight | 3.0kg/Sheet | 2.8kg/Sheet |
| Quantity in 20FCL | 9000PCS | 9500PCS |
3).Rainbow Tile,
| Model No. | Zj01 | Zj02 |
| Tile size | 1400mm*420mm | 1340mm*420mm |
| Installed Exposure | 1350mm*370mm | 1290mm*370mm |
| Tiles per Sqm | 2sheets | 2.08Sheets |
| Installed Weight | 3.0kg/Sheet | 2.8kg/Sheet |
| Quantity in 20FCL | 9000PCS | 9000PCS |
4).Shingle Tile,
| Model No. | Zj01 | Zj02 |
| Tile size | 1400mm*420mm | 1340mm*420mm |
| Installed Exposure | 1350mm*370mm | 1290mm*370mm |
| Tiles per Sqm | 2sheets | 2.08Sheets |
| Installed Weight | 3.0kg/Sheet | 2.8kg/Sheet |
| Quantity in 20FCL | 9000PCS | 9000PCS |
5).Makuti Grained Tile:
| Model No. | Zj01 | Zj02 |
| Tile size | 1400mm*420mm | 1340mm*420mm |
| Installed Exposure | 1350mm*370mm | 1290mm*370mm |
| Tiles per Sqm | 2sheets | 2.08Sheets |
| Installed Weight | 3.0kg/Sheet | 2.8kg/Sheet |
| Quantity in 20FCL | 8000PCS | 8000PCS |
Alice Xu: Mobile:0086+13165271533
Skype:aliceqqx
email:aliceconnector@
Whats app: +8613165271533
Linyi Jinhu Color Coating Aluminum Industry Co.,Ltd
COLOR CHART
Main physiochemical index of stone coated steel roofing tile
1.Water resistance:After 24h test without anomalies
2.Heat resistance:No abnormalities after 90°C*5 test
3..Low temperture resistance:After -40°C*24h test without anomalies
4.Alkaline resistance:After 48h test without anomalies
5.Acid resistance:After 48h test without anomalies
6.Resistance salt spry:After 240h test without anomalies
7.Cycle of freezing and thawing:After 20 times test without anomalies
8.Artificial weathering:After 1000h test without anomalies
The feature of stone coated steel roofing tile
1.Enviroment Friendly:The light weight nature of the tiles means that less timber is used in the roof stucture as compared to traditional roof tiles.Water harvested is safe for consumption.
2.Cost effective:It is so far the most economical roof age,for it is waterproof,freezing tolerance,fireproof,aging-resistant,and erosion resistant.
Up to 40% less timber is used on the roof structure and no polythence or iron sheet underlay is required for roof pitches between 5 and 60 degrees.
3.Maintenance Free:The tiles have up to 30 years warranty thus guaranteeing quality.
4.Security:The tiles are nailed into the battens using serrated nails thus providing burhlar proofing.
5.Structural Strength:No bending of tiles during installation
6.Heat and sound insulation:Compare to the galvanized sheet,aluminum-sinc is more durable,heat-resisting,heatproof and anti-corrosion.It is genenrally believed that steel roofing sheet can guarantee 30 more yaers without being rusted or eroded in various conditions.
7.Ultraviolet/Corrosion resistant:The acrylic paint prevents penetration of UV rays.The zinc or Alu-zinc coating prevents corrosion
8.Leak proof:The interconnection of the tiles is at 90 degrees thus preventing any water penetration
9.Easy to install:This material is flexible and easy to cut.Approximately2 PCS is enough for ever aquare meters.It is safe and convenient in installation and maintance.Roofing is done in a matter of days and not weeks thus saving on labor cost.
10.Algae and Fungi Resistant:The paint used prevents fungi growth
11.Color Diversity:LYSF roofing tiles come in a wide range of colors to suit individual preferences.The colorful vermiculite has been processed at high temperature,thus to be brightly-colored,and never faded.Now the product is widely used the entire world.
