Carport for House

Specifications

Steel Carports
1, Easy to install
2, attractive apprance
3, low cost

 Steel  Carports



Some information about the products .



1.       Vertical Support #1:  For each 6-Car Carport, there are three vertical support posts  (standing between car #1/car #2,  car #3/car #4, and car #5/car #6)

Main Vertical Beam is rectangular HSS steel tubing, 18 feet 4 inches long, 8 inches x 4 inches, .250 inch thick steel

2 Diagonal Support Beams are square HSS steel tubing,  4 inches by 4 inches, .125 inches thick, mounted to the vertical support



2.       Roof Support #2:  For each 6-Car Carport, we need 6 Roof Support Beams.

Rectangular HSS steel tubing 10 feet long, 6 inches by 4 inches, .125 inches thick

.25 inch thick Steel Foot plates (Cleats) welded to each end, with L-Shaped Cleat support welded to middle to bolt to C-Purlin

6 holes need to be drilled in each Cleat



3.       C-Shaped Purlin #3:  (Can be lipped or plain – see attached file Perlin.jpg)   For each 6-car Carport, we need 12 pieces of Purlin

CEE Steel 27 feet long, 8 inches by 2.5 inches, 12 GA (.125 inches thick)

No Holes need to be drilled into these pieces.



4.       Roof Panels:   these panels come standard in 3 feet 2 inches wide by 10 feet long in corrugated steel 26 Gauge  1 and ¼ inch R-Panel.

These sections have a 2 inch overlap, so to cover 54 feet we need on both sides, we need 36 pieces.

If you can make these pieces 6 feet wide and do less pieces, that is fine.  Whatever is best.



5.       Ridge Cap:  Steel 6 inches wide V-shaped 27 feet long, 2 pieces to span 54 feet.
