FCST15 Microduct Connector
Brief Introduction:
The Push-Fit Connectors make splicing Micro Duct fast and easy. Simply push the Micro Ducts into the center of the coupling. No tools are required. The coupler can be connected and disconnected 10 times and still maintain the high performance requirements for air blown installation systems.
Push-Fit Micro Duct connector operate at 15 BAR (218 psi) with a maximum permissible leakage rate of 1cc/min. This is equivalent to 1 bubble every 3 seconds. Higher pressures have been used in the field with no increase in leakage rate. Quick Burst rating is 25 BARS (363 psi).
Specification:
Model No. |
Part Name |
Blow Pressure |
Pull Strength For HDPE tube |
Pull Strength For LSZH tube |
Life time |
FCST15103 |
5/3.5mm connector |
>18bar |
≥350N |
>150N |
10 Years |
FCST15106 |
7/5.5mm connector |
>18bar |
≥350N |
>150N |
10 Years |
FCST15105 |
7/3.5mm connector |
>18bar |
≥350N |
>150N |
10 Years |
FCST15107 |
8/3.5mm connector |
>18bar |
≥350N |
>150N |
10 Years |
FCST15108 |
8/5.5mm connector |
>18bar |
≥350N |
>150N |
10 Years |
FCST15109 |
10/8 mm connector |
>18bar |
≥350N |
>150N |
10 Years |
FCST15110 |
12/10mm connector |
>18bar |
≥350N |
>150N |
10 Years |
FCST15111 |
14/10mm connector |
>18bar |
≥350N |
>150N |
10 Years |
FCST15112 |
16/12mm connector |
>18bar |
≥350N |
>150N |
10 Years |
FCST15113 |
16/14mm connector |
>18bar |
≥350N |
>150N |
10 Years |
Technical Specification:
Product Picture:
Pckage picture:
Desigh Lifetime:
The connector shall meet all performance requirements over a minimum period of 10 years at the normal condition.
Exhibition:
•Packing: By carton
•Shipping: By air. By sea. By TNT. By DHL.By UPS etc.
ODM,Product training,FTTH solution consultant,After sale service,Fiber blowing solution consultant, Fiber tools&toolkits consultant
•Production Capacity: We can provide 50,000pcs per week
•R&D department: 10 designer
•The Exhibition experience:ECOC,OFC,NETCOM,Local Exhibition
•Cooperation customers:CMCC,Huawei,Tyco,ZTE,3M, Dura-Mine,GM,MG...
•Transaction Term: EXW,FOB,CNF,CIF
•Payment Term: 100% T/T in advance
