Specifications
1,solar keymark EN12975 and SRCC Approved2,copper heat pipe
3,temp.: -40 to 300 degrees
5, suitable for cold area
OUR GOAL IS TO MAKE YOU CLEAR ABOUT YOUR PRODUCTS AT YOUR OFFICE!!!
Heat Pipe Solar Collector
Model: GDL-SP58-1800-15
Tube no: 15
Fliud volume: 0.9 liters
Apreture area: 1.419m2
Absord Area: 1.135m2
Gross Area: 2.366m2
Volume:
N.W:
G.W.:
Features:
1) Reliable and efficient twin-glass solar vacuum tubes
2) Copper heat pipes for rapid heat transfer
3) Easy plug-in installation
4) Free maintenance
5) Suitable for mains pressure water
6) Corrosion resistant silver brazed copper header
7) Stable solar conversion during the day
8) Pressurized solar collector provides hot water with pressure, comfortable
9) The perfect solar collector for domestic solar water heater systems
10) Ideal for commercial solar water heating applications
Material Specifications:
1) Glass tube: new trivalent element vacuum tube, coating AL-N/SS/CU, 58*1800mm
2) Heat Pipe Material: TU1 Copper, length 1707mm
3) Heat PipeDiameter: condenser dia14mm, body dia 8mm
4) Manifold header pipe: TP2 copper dia 35mm
5) Manifold casing (Head box): anodized aluminum alloy
6) Insulation: rock wool with polyurethane foam
7) Bracket: anodized aluminum alloy
8) Tube holder: UV stabilized nylon
9) Seals: Silicon seal
10) Contact sheets: Aluminum fin
11) Anti-freezing fluid: pure water/glycol
12) Working Pressure: 6 bar
13) Max test pressure: 12bar
14) Working Temperature: -40 to 300 degrees
Structure of Heat Pipe Solar Collector
Heat Pipe Solar Collector for Domestic Heating:
Large Project of Heat Pipe Solar Collector for Swimming Pool Heating, Hotel and so on
Size of Heat PIpe Solar Collector:
Available Models of Heat Pipe Solar Collector (Appoved by Solar Keymark EN12975 & SRCC)
Model |
Tube No. |
Fluid volume /L |
Aperture Area /m2 |
Absorb Area / m2 |
Gross Size W * L /mm |
Flat roof install size W*L*H/mm |
GDL-SP58-1800-12 |
12 |
0.72 |
1.135 |
0.908 |
970*1980 |
970*1335*1425 |
GDL-SP58-1800-15 |
15 |
0.9 |
1.419 |
1.135 |
1195*1980 |
1195*1335*1425 |
GDL-SP58-1800-18 |
18 |
1.08 |
1.703 |
1.362 |
1420*1980 |
1420*1335*1425 |
GDL-SP58-1800-20 |
20 |
1.2 |
1.892 |
1.514 |
1570*1980 |
1570*1335*1425 |
GDL-SP58-1800-24 |
24 |
1.44 |
2.270 |
1.816 |
1870*1980 |
1870*1335*1425 |
GDL-SP58-1800-30 |
30 |
1.8 |
2.838 |
2.270 |
2320*1980 |
2320*1335*1425 |
