TESUNHO TH-UV7R Pofung Dual Band Radio Ham Radio

TESUNHO TH-UV7R Pofung Dual Band Radio Ham Radio thumbnail-1
TESUNHO TH-UV7R Pofung Dual Band Radio Ham Radio thumbnail-2
TESUNHO TH-UV7R Pofung Dual Band Radio Ham Radio thumbnail-3
TESUNHO TH-UV7R Pofung Dual Band Radio Ham Radio thumbnail-4
TESUNHO TH-UV7R Pofung Dual Band Radio Ham Radio photo-1
TESUNHO TH-UV7R Pofung Dual Band Radio Ham Radio photo-2
TESUNHO TH-UV7R Pofung Dual Band Radio Ham Radio photo-3
TESUNHO TH-UV7R Pofung Dual Band Radio Ham Radio photo-4
US$ 7 - 35 MOQ: 2 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
TESUNHO
Model Number:
TH-UV7R
Contact Supplier Request Quote Chat Now
Quanzhou Fengze Tesunho Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN;XIAMEN ;HANGZHOU
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name TESUNHO
Model Number TH-UV7R
Type Handheld
Dimensions 110MM*58MM*28MM
Frequency Range 136-174MHZ;220-260MHZ;40-470MHZ
Storage Channel 128
Talk Range 3-10km

Product description:

1)TESUNHO TH-UV7R dual band dual display walkie talkie

TESUNHO TH-UV7R pofung dual band radio ham radioTESUNHO TH-UV7R pofung dual band radio ham radio



Item number TH-UV7R
General
Frequency Range 1)76-108MHz(FM Receive only)
2)136-174MHz  &   400-520MHz      or
3)136-174MHz   &   245-246MHz
Channel No. 128*2
Frequency Stability ±2.5ppm
Antenna High gain antenna
Antenna Impedance 50Ω
Operating Voltage DC 7.2V
Mode of operation Simple or semi-duplex
Dimension(W x H x D) 100 x 52 x 32 mm
Weight 250g(including battery, antenna)
Transmitter
Output power ≥4W(H)   ≥0.5W(L)
Modulation Mode 16kΦF3E / 11kΦF3E
Maximum deviation <5kHz(Wide) / <2.5kHz(Narrow)
Spurious Radiation <7μW
Adjacent Ch. power ≤-65dB(Wide) / ≤-60dB(Narrow)
Pre-emphasis characteristics 6dB
Current ≤1.6A(5W)
CTCSS/DCS deviation 0.5±0.1kHz(Wide) / 0.3±0.1kHz(Narrow)
Intermediation sensitivity 8-12mv
Intermediation distortion <10%
 Receiver
RF Sensitivity -122dbm(12db SINAD)
Audio power ≥0.5W
Audio Distortion ≤10%
Intermediation ≤-65dB(Wide) / ≤-60dB(Narrow)
Selectivity ≤-65dB(Wide) / ≤-60dB(Narrow)
Spurious Rejection ≤-65dB
Blocking ≥85dBuv/m





2)TESUNHO TH-UV7R dual band dual display walkie talkie



Dual band, dual display, dual standby A/B band independent operation
128 groups channels storage FM radio and 25 stations storage
Wide/Narrow Band(25kHz/12.5kHz) 0-9 grades VOX selectable
Chinese/English voice prompt CTCSS/DCS and scanning
1750Hz tone PTT & ANI ID
Priority transmit selectable 0-9 grades squelch level setting
LED display mode Keypad beeper setting
Transmit over beeper Dual watch/monitor
Receive saving function Auto keypad lock
Power-on display Battery power voltage
Power-on message Repeater offset function
Channel name display and setting Reapter shift direction
VFO step function Shortcut menu operation mode
Emergency Alarm DTMF encoder & decoder(optional)
Remote skill/stun/activate(optional) High/Low TX power selectable
Busy channel lock-out(BCLO) Transmitter time-out timer(TOT)
Voice companding Tri-color background light selectable
PC programmable Wire clone



3)TESUNHO TH-UV7R dual band dual display walkie talkie
TESUNHO TH-UV7R pofung dual band radio ham radioTESUNHO TH-UV7R pofung dual band radio ham radioTESUNHO TH-UV7R pofung dual band radio ham radio



  4)TESUNHO TH-UV7R dual band dual display walkie talkie

 TESUNHO TH-UV7R pofung dual band radio ham radio

Warranty for Walkie talkie



Item Period Service
Main Unit

 1 Year Warranty

finish maintainance within 1-15days

after receiving the returned units
Battery Half Year Warranty

Within Half Year:send you  new one if it is not manually damaged;

Beyond Half Year:supply cost-effective renovation
Charger Half Year Warranty

Within Half Year:send you brand new one if it is not manually damaged;

Beyond Half Year:supply cost-effective renovation





5)TESUNHO TH-UV7R dual band dual display walkie talkie





TESUNHO TH-UV7R pofung dual band radio ham radio





6)TESUNHO TH-UV7R dual band dual display walkie talkie



 TESUNHO TH-UV7R pofung dual band radio ham radio
