ANYTALK ham radio, the legitimate use of green and healthy.
Walkie Talkie the Green public radio, can completely relieve your worries!
Products: |
Handheld Radios |
Item No.: |
AT-Q2 |
Features: |
CTCSS/DCS |
General Specifications | |
Power Supply |
7.5V DC ±20% |
Operating Temperature |
-25°C~ + 55°C |
Number of Channels |
128 |
Dimensions |
120*57*30mm |
Weight |
215g |
Transmitter Specifications | |
Frequencies - Full Band split |
VHF: 136MHz~174MHzUHF:400MHz~470MHz |
Frequency Stability(-25 to 55, 25 Ref) |
2.5ppm |
Power Output |
5W |
Modulation Limiting |
±≤5KHz 25KHz |
FM Hum & Noise |
45dB 25KHz, |
Conducted/Radiated Emission |
-36dBm < 1GHz, -30dBm > 1GHz |
Adjacent Channel Power |
-65dB 25KHz, |
Audio Response (300-3000Hz) |
+3 ~ -3 dB |
Audio Distortion |
< 5% |
Receiver Specifications | |
Frequencies - Full Bandsplit |
VHF: 136MHz~174MHz UHF:400MHz~470MHz |
Sensitivity(12 dB SINAD)EIA |
0.25μV 12.5KHz/25KHz typical |
Intermodulation EIA |
60 dB |
Adjacent Channel Selectivity |
65 dB 20/25KHz |
Spurious Rejection |
70 dB |
Rated Audio |
1W |
Audio Distortion @ Rated Audio |
5% |
Audio Response (300-3000Hz) |
+3 ~ -3 dB |
Conducted Spurious Emission |
-58 dBm<1 GHz, -47 dBm>1GHz |
Type: AT-Q2 two way radio, walkie talkie, transceiver, interphone, 2 way radio, talkie walkie
Color: black, red, orange
Weight: 1KG/SET
Size: 120*57*30MM for radio body
Using rechargeable walkie-talkie for the first time, please charge for 16 hours.
Turn off your computer before removing the battery.
Please do not use hand to pick up the antenna, hold the antenna will affect the effective wireless intercom call range.
Use the walkie-talkie, you should keep it vertical distance of 5.0 to 7.0 cm, and keep your face.
Please try to use while driving handsfree speaker and the closing words.
Keep your intercom televisions, computer monitors and other screen to maintain a distance greater than 10cm, to avoid being magnetized.
The interphone Do things together with other metal-containing storage.
Walkie-talkies may interfere with some hearing aids, with your hearing aid manufacturer to discuss alternatives.
Try to place in the medical walkie-talkie off, so as not to affect the use of medical equipment.
Do not use in airports and on aircraft. If so, prohibited driving the car to the side of the road and then.
In potentially explosive areas must remain shut down, unless it is dedicated intercom dangerous areas (for example, Factory Mutual, CAS, or UL certified).
