400kw ac frequency inverter 50hz to 60hz vfd for power generator
- 3000 Unit / Units per Month
- SHANGHAI
- T/T
- electric ac motor speed controller 480V 32A 18kw 3phase Input&3Phase Output AC frequency converter with 18 months warranty
- 45kw 380v vector control ac frequency converter 50hz 60hz motor frequency inverter 3 phase Power Frequency Converter for Pump
- EM15-G3 General used Vector control Frequency inverter(3 phase )
- EMHEATER soft starter
- EM GS2 7.5KW 220V 240V Motor Soft Starter for Submersible Pump deep well
- Inverter AB PowerFlex®7 Converter 22CD012N103 Inverter PowerFlex 400- 5.5 kW (7.5 HP) AC Drive
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | AUBO | Model Number: | AVF508 |
Output Power: | Other, 0.75KW~400KW | Output Type: | Triple | Size: | as per product |
Weight: | as per product | Input Voltage: | 380/220VAC±15% | Output Voltage: | 0~ rated input voltage |
Type: | Other, AC to DC to AC | Output Frequency: | 0~600 Hz | Output Current: | 750A |
Product Description
400kw ac frequency inverter 50hz to 60hz vfd for power generator
Nanjing Aubo Electric Co. Ltd, simply as Aubo, is specialized in producing variable speed motor drive and soft starter,for both medium and low voltage , as well as simple PLC and motor protector. Aubo deals with both product trading and engineering solution. It also distributes VACON inverter from Finland, and AuCom soft starter from New Zealand.
Aubo has a factory in Nanjing and sales offices across the country, while the international customers are to be looked after by its Shanghai office.
Performance Features:
u Control Mode:Vector control without PG,V/F control;
u Overload Capacity:150% FLC for 60s;180% FLC for 10s;
u Start Torque:vector cotrol without PG,0.5Hz/150%(SVC);
u Speed ratio: vector cotrol without PG ,1:100;
u Speed Control Accuracy: vector cotrol without PG ,±0.5% max. speed;
u Carrier Frequency:0.5~15.0kHz;
Functions:
u Frequency setpoint options:digital,analog,serial comms,multi-level speed , PID, etc;
u PID control;
u multi-level speed control: 8 speed levels;
u Non-stop during instaneous power off;
u QUICK/JOG:functional quick button to be defined by user freely;
u Voltage auto-tuning:When the power supply viberates, the output voltage is kept constant automatically
u More than 25 protections:Over current, over voltage, under voltage, over temperature, phase loss, over load, etc.
Interface Features
u Programmable DI:6 inputs;
u Programmable AI:AI1:-10~10V input,AI2:0~10V or 0~20mA input;
u Open Collector Output:1 output;
u Relay Output:1 output;
u Analog Output:1 output,optional ,0~20mA or 0~10V;
We have several transport options for customer to choose:
1, Transport by sea
2, Transport by truck
3, Transport by train
4, Transport by express service
5. Transport by air, (to be confirmed )
1.Delivery term: FOB, CIF,EXW are available.
2.Payment term:30% prepayment, 70% before dispatching
3.Production lead-time: 1-2 weeks
4.Shipping lead-time: 4-6 weeks
5.Logistics: best service forwarder with good price, long term partner.
1,We can design the job for your specs or your project
2,We provide site commissioning on demand
