6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw

6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw thumbnail-1
6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw thumbnail-2
6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw thumbnail-3
6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw thumbnail-4
6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw thumbnail-5
6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw photo-1
6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw photo-2
6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw photo-3
6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw photo-4
6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw photo-5
US$ 40,000 - 500,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
AUBO
Model Number:
AMVI series
Contact Supplier Request Quote Chat Now
Nanjing Aubo Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name AUBO
Model Number AMVI series
Output Power Other, 200kw~8000kw
Output Type Triple
Size D1250*W5150*H2200(MM)
Weight as the product
Input Voltage 3AC,6KV
Output Voltage 0-6KV
Type DC/AC Inverters
Output Frequency 0-50(60)HZ
Output Current 26A~964A



Company Information



Nanjing Aubo Electric Co. Ltd, simply as Aubo, is specialized in producing variable speed motor drive and soft starter,for both medium and low voltage , as well as simple PLC and motor protector. Aubo deals with both product trading and engineering solution. It also distributes Vacon inverter from Finland, and AuCom soft starter from New Zealand.

Aubo has a factory in Nanjing and sales offices across the country, while the international customers are to be looked after by its Shanghai office.



Product Description

 AMVI inverter is a high tech product with our own intellectual property rights and good performance, for the speed control of 3kv / 6kv/10kv medium voltage motor.

The advantage:

  1. Perfect output waveform, harmonics free
  2. High power factor, high efficiency
  3. Motor speed control & soft start enabled
  4. Reduce operation and maintenance cost
  5. Easy operation
  6. Perfect protection and auto-diagnosis for fault

6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw





Typical Application



1. Thermal powerindustry: induced draft fan, blower, dust collection fan, compressor, sewage pump, boiler feed pump etc.

2. Petrochemical industry: main pumps, submersible pumps, injection pumps, circulating pump, boiler feed pump, halogen water pump, fan, descaling pump, mixer, gas compressors, extrusion machine, etc

3. Mining and metallurgy: slurry pump, induced draft fan, blower,, dust removal fan, descaling pump, centrifugal feed pump, etc Cement manufacturing: water pump, boiler feed pump, halogen water pump, fan, descaling pump, mixer, gas compressors, induced draft fan, preheat tower fan,pressure blower fan, cooler dust cleaning fan, ball mill for raw material, kiln gas fan, cooler exhausting fan, classifier fan, the main dust collection fan, etc

4. Water supply and wastewater treatment: main line pumps, submersible pumps, injection pumps, circulation pump, sewage pump, cleaning pump, biological processing tower pump

5. Other industry: pulp beater, pumps, rotating machinery, wind turbines, wind tunnel, etc





6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw



Model Rated Current(A) Rated Power(KW) Model Rated Current(A) Rated Power(KW)
AMV-IV06-200 26 200 AMV-IV10-0220 17 200
AMV-IV06-250 30 250 AMV-IV10-0250 19 250
AMV-IV06-280 33 280 AMV-IV10-0280 21 280
AMV-IV06-315 37 315 AMV-IV10-0315 24 315
AMV-IV06-355 42 355 AMV-IV10-0355 27 355
AMV-IV06-400 48 400 AMV-IV10-0400 30 400
AMV-IV06-450 54 450 AMV-IV10-0450 33 450
AMV-IV06-500 60 500 AMV-IV10-0500 37 500
AMV-IV06-560 67 560 AMV-IV10-0560 41 560
AMV-IV06-630 75 630 AMV-IV10-0630 46 630
AMV-IV06-710 84 710 AMV-IV10-0710 51 710
AMV-IV06-800 95 800 AMV-IV10-0800 57 800
AMV-IV06-900 106 900 AMV-IV10-0900 64 900
AMV-IV06-1000 118 1000 AMV-IV10-1000 71 1000
AMV-IV06-1120 132 1120 AMV-IV10-1120 79 1120
AMV-IV06-1250 146 1250 AMV-IV10-1250 88 1250
AMV-IV06-1400 164 1400 AMV-IV10-1400 98 1400
AMV-IV06-1600 185 1600 AMV-IV10-1600 112 1600
AMV-IV06-1800 220 1800 AMV-IV10-1800 127 1800
AMV-IV06-2000 229 2000 AMV-IV10-2000 141 2000
AMV-IV06-2240 251 2240 AMV-IV10-2250 157 2250
AMV-IV06-2500 281 2500 AMV-IV10-2500 175 2500
AMV-IV06-2800 324 2800 AMV-IV10-2800 295 2800
AMV-IV06-3150 363 3150 AMV-IV10-3150 230 3150
AMV-IV06-3550 428 3550 AMV-IV10-3550 259 3550
AMV-IV06-4000 482 4000 AMV-IV10-4000 290 4000
AMV-IV06-4500 542 4500 AMV-IV10-4500 326 4500
AMV-IV06-5000 602 5000 AMV-IV10-5000 362 5000
AMV-IV06-6000 723 6000 AMV-IV10-5600 405 5600
AMV-IV06-7000 844 7000 AMV-IV10-6300 455 6300
AMV-IV06-8000 964 8000 AMV-IV10-7100 512 7100



Our Service

1,We can design the job for your specs or your project

2,We provide site commissioning on demand



Packaging

6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw

Shipping



We have several transport options for customer to choose:



1, Transport by sea



2, Transport by  truck



3, Transport by train



4, Transport by express service



5. Transport by air,  (to be confirmed )





Trade term

1.Delivery term: FOB, CIF,EXW are available.



2.Payment term:30% prepayment, 70% before dispatching



3.Production lead-time: 1-2 weeks



4.Shipping lead-time: 4-6 weeks



5.Logistics: best service forwarder with good price, long term partner.

Certifications

6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw6kv Ac Electric Motor Speed Control Ac Drive Inverter Power Frequency Inverter 400kw
