Specifications
video / stereo audio/ data RS232(bidireactional)over fiber transmitter and receiver
Please please do not hesitate to trust!
We are your best choice for Chinese parnter
Because of 10 year experienced, 3 year warranty, professional technical service and good price
Customer design and special requirements are always welcome!
Overview
The HC3611 transmits 1-channel DVI/VGA video signal and 1-channel stereo audio and 1-ch data RS232 over one fiber, single mode or multimode, without compression, scaling and adjustments. It is ideal for Digital signage, broadcast or corporate studio, auditorium, stadium and theater, airport or transportation hub, distance learning, and surgical or medical imaging applications, to name a few.
Features
# 1-channel DVI/VGA video signal of computer and 1-channel stereo audio and 1-ch data RS232 over one fiber optic
# 10-bit digital video encoding and uncompressed transmission technology
# Applied to the needs of computer long-distance transmission of industrial monitoring, large venues etc
# Strictly selection material and quality control in order to ensure high quality and high reliability
# DVI/HDMl interface optional
# System status could be monitored by the power and other parameters LED indicator
# Compact size
# Excellent cost performance
# SMT Surface Mount Technology
# Stand-alone
# Lower power consumption and free installation, debugging
# Also Support VGA signal
Specification
Video | |
Channel |
1 |
Type |
RGB with stand-alone and sync H, V |
Input level |
1Vp-p |
Output level |
1Vp-p |
Bandwidth (-3 dB) |
300MHz |
Digital bits wide |
10bits |
Connector |
HD-15(DVI,HDMI optional) |
Resolution |
•640X480 @ 70fps |
•1920X1080 @ 25fps | |
•1024X768 @ 60fps | |
•800X600 @ 70fps | |
•1600X1200 @ 30fps | |
• 1280X1024 @ 30fps | |
•720X576 @ 50fpsv | |
•720X480 @ 60fps | |
•1440x900 @ 30fps | |
•1280X720 @ 30fps | |
•1680x1050 @ 30fps | |
•1400 x1050 @ 30fps | |
•1360x768 @ 30fps | |
Audio | |
No. |
1 |
Input/output level |
5Vp-p,unequilibrium |
Connector |
Standard 3.5 mm stereo headphone jack |
RS232 indication | |
Input/output interface |
9-hole standard RS232 socket |
Signal rate |
≥115200bps |
Signal level |
RS232 standard level |
Optics | |
Type |
Single-mode |
Output optical power |
-5 ~ -10dBm |
Receiver sensitivity |
18dBm |
Wavelength |
1310/1550nm |
Connector |
FC/PC (SC/PC optional) |
Max. Link loss |
12dB (bigger options) |
Connector |
FC/PC (SC or ST optional) |
Power and environmental indicator | |
Stand-alone power |
5W |
Insertion power |
5W |
Power adapter |
220VAC to 12VDC/1A |
Operating temperature |
-40°C to +70°C |
Relative humidity |
< 95% (no condensation) |
Dimension | |
Stand-alone size |
184 x 140 x 45 (mm) |
Insert size |
260 x 173 x 40 (mm) |
Stand-alone weight |
2 2.0Kg |
Insert weight |
1.5Kg |
Applications (for your reference)
# Remote OB Van/Truck Video Feeds
# Broadcast Studio Camera Feeds
# Long-haul Signal Transport
# TV station/video conference
# Lecture Hall Projector Connectivity
# Medical / Surgical Room Broadcast
# Building to Building video conference calling
# Small corporate campus video links
Successful cases
