2016 hot selling WER UV FLATBED PRINTER
WER UV Flatbed Printer. Model No. M10
This machine is our UV Flatbed Printer, also known as multiple UV printer. Its printing size is 2.05 x 3.2m. Using the UV ink it can print excellent images on various rigid medias, such as glass, acrylic, wood, PVC foam board, KT board, MDF, alunimum, cellphone case, ceramic tiles, and so on. Also, it offers various ways of printing the white color. It can print the three-layer spot colors which means it can print color-white-color at one time!
The printheads can be KM-512MH-14PL, KM-1024MHB-14PL or Ricoh Gen5 7PL. The printing colors can be Lc Lm Y M C K, and White is optional!
Features
• High resolution and high-quality piezo electric printhead can achieve excellent production performance and vivid bright colors
• 4 color printing: YMCK
• 5 color printing: YMCK+W or YMCK WW
• 6 color printing: Lc Lm Y M C K
• 7 color printing: Lc Lm Y M C K W or Lc Lm Y M C K W W
• 8 color printing: Lc Lm Y M CK W V
• Excluding the use of VOC (Volatile Organic Compounds) in the UV curable ink. The ink is environmental friendly and no smell
• With advanced Automatic Height Detector which can detect the material thickness and find a good height position for best quality printing
• Drawer-type UV lamp cassette makes it easy to replace the UV lamp
• Equipped with Japanses THK mute guide rail
• Carriage is with a crash sensor with high sensitivity to ensure that the printhead will not be accidentally damaged
• The white ink catridge is with the automatic stiring and circulation system, which avoids the clog of the White printhead.
• Easy operation menu. User-friendly
General Information |
|
||
Model |
WER M10 |
||
Catagory |
UV Flatbed Printer |
||
Printing Size |
2.05 x 3.2m |
||
Printing | |||
Print Technology |
drop-on-demand piezo electric inkjet |
||
Printhead |
KM-512MH-14PL/KM-1024MHB-14PL/Ricoh Gen5 7PL |
||
Printhead Control |
Printhead temperature and voltage are adjustable in software |
||
Ink Type |
UV curable Ink |
||
Ink Reservoir |
Refillable on the fly while printing/2000ml |
||
Rip Software |
Photo Print/ONYX/Caldera |
||
Color Management |
ICC based color, curves adjustment, density adjustment |
||
File Format |
Tiff, Jpeg, Pstscript, eps, pdf |
||
Media Thickness |
1-100mm |
||
Printhead QTY |
KM-512MH-14PL |
|
|
4-8pcs |
|
||
Resolution |
KM-512MH-14PL/KM-1024MHB-14PL |
|
|
720 x 720 dpi |
|
||
720 x 1080 dpi |
|
||
720 x 1440 dpi |
|
||
Printing Speed |
KM-1024MHB-14PL |
|
|
4 pass 28 sqm per hour |
|
||
6 pass 19 sqm per hour |
|
||
8 pass 15 sqm per hour |
|
||
Print Colors |
4 colors (CMYK), 6 colors (Lc Lm CMYK), White/Varnish optional |
||
Drying System |
UV Lamp with three power levels |
|
|
Medias | |||
Rigid materials: glass, acrylic, PVC foam board, KT board, Wood, WPC, Metal panels,ceramic tiles, MDF, etc. |
|||
Outdoor Life of finished printing |
|
||
3 years (use WER ink) |
|
||
Dimensions and Weight | |||
Dimensions |
4.8 x 3.93 x 1.38m |
|
|
Weight |
2160kg |
|
|
Operation | |||
Power Supply |
50/60Hz 220V(10%)>30A |
|
|
Operation Environment |
20°C to 28°C |
|
|
Humidity |
40% to 60% |
|
|
Warranty | |||
one year |
|
||
