Hebei jinbaili Ridge Cap roof roll forming machine
Specification:
1) Can produce Metal stud. drywall track, rail, light keel, Ceiling Tray
2) High speed work, perfect finish
3) European quality, work smoothly.
Machine Configuration:
Decoiler, Feeding Applicator, Roll Forming Unit, Computer Control System, Hydraulic Punching, Hydraulic Cutting, Output Table
The Chart of Process Flow
Uncoiling→Feeding material into machine→Roll forming→Measuring length→ Step formed→
Auto cutting→Products receiving
Technical parameters:
No. |
Main Parameter of Keel Roll Forming Machine |
|
1 |
Suitable to process |
Color steel plate |
2 |
Width of the plate |
700mm |
3 |
Rollers |
12 rows |
4 |
Dimensions |
3500*1350*1510mm |
5 |
Power |
5.5+4kw |
6 |
Thickness of the plate |
0.4mm |
7 |
Productivity |
15-20m/min |
8 |
Material of the cutting blade |
Cr12 |
9 |
Diameter of the roller |
Φ50mm |
10 |
Weight |
About 3.6T |
11 |
Voltage |
380V 50Hz 3phases |
15 |
Control system |
PLC control |
Component Specification
No |
|
Technical Specification |
1 |
Manual Uncoiler |
Usage:It is used to support the steel coil and uncoil it in a turnable way. The steel coil is uncoiled by hand. Loading capacity: 5T,Inner diameter: 1000mm |
2 |
Feeding Table |
Put the raw material(steel plate) through the beach to manufacture and process, it can guarantee that the products are neat, parallel and everything is uniformity. Please refer to the equipment regulation to know the function of locate angle iron. |
3 |
Main Roll Forming Machine |
Material of rollers:45# steel,roller surfaces polishing, hard plating , The polished surface and the heat treatment towards the molds also can keep the molding plate surface smooth and not easy to be marked when it is being stamped |
4 |
Hydraulic System Computer Control Cabinet |
Power:4kw,Hydraulic oil: 40# hydraulic oil into the hydraulic oil tank ,the pump drive the cutter machine to begin the cutting job. The target piece`s length is adjustable and digit of it can be adjusted. Computed mode has two modes: automatic and manual one. The system is easy to operate and use |
5 |
Shearing Mechanism |
It adopts the hydraulic drive and automatic location to decide the dimension and cut the target products. Material of blades: Cr12,quenching treatment |
6 |
Output Table
|
It adopts welded steel and supported roller to transmit the products,which is used to collect the finished products. |
All technical parameters can be changed, according to user's need.
Photos of Machine:
1.Installation and Training of Machine Manufacturer:
a.If buyers visit our factory and check the machine, we will teach you how to install and use the roll forming machine for sale , and also train your workers/technician face to face.
b.Without visiting, we will send you user manual and video to teach you to install and operate.
c.If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.
2. After Service of Roll Forming Machine for Sale:
a.One year guarantee for whole roll forming machine for sale.
b.24 hours technical support by email or calling
c.If there is any problem found of steel roof sheet roll forming machinery, we will repair roll forming machine for sale for free in one year.
Company Introduction:
We are a Chinese company which specially produce roll forming machine.It' named Boutou jinbaili roll forming machinery Co.,Ltd ,which is one of the earliest companies dealing with exporting roll forming machines.Owning advanced equipment and excellent designer our products has reached leading level by high efficiency, high precision and low waste.
We have high technological background,advanced and mature production equipment and perfect means of inspection.We not only produce different type of professional roll forming machine,but also developed intelligent automatic production line of roll forming equipment,C shape purline machine and precipitator anodde plate forming machine ect. We have developed automatic production line of roll forming machine,roof panel,wall panel forming machine series,Glazed tile roll forming machine series,Floor deck forming machine series,Highway barrier forming machine series,double deck color steel tile roll forming machine series,C,Z shaped steel purline machine series,ach camber machine series and bending machine series,insulated sandwich panel machine on the base of traditional roll forming machine ,fair frame and standard model.
