Help CenterSolar Charge Controller With 10A/12V
Related Products
-
10A PWM Solar Charge Controller for Solar Street Light and Solar SystemUS$ 8.5 - 9.4MOQ: 6 Sets -
Solar Charge Controller With Timer and Lighting ControlledUS$ 8 - 10.5MOQ: 10 Boxes
-
10A Pwm Solar Water Pump Controler for Solar Street Lamp SystemUS$ 10 - 10.5MOQ: 10 Pieces
-
High-conversion Efficiency Pwm Solar Charge ControllerUS$ 8 - 10.5MOQ: 5 Boxes
-
10A Pwm Solar Charge Controller Inverter for Solar Street Lamp SystemUS$ 10 - 10.5MOQ: 10 Pieces
solar charge controller
solar controller,solar system controller designed to reduce pressure loaded,no-load loss.with short circuit protection;reverse current protection, reverse polarity protection; lightning protection; overcharge protection ;overdischarge protection etc.
Technical parameters
Items |
Solar Charge Controller
|
Rated Charge Current |
10A,12V/24V Auto |
Rated Load Power |
Rated Voltage:12V:≤100W Rated Voltage:24V:≤200W Note:Depend on the power of LEDs |
System Voltage |
12V/24V Auto |
No-load Consumption |
≤6mA |
Recharge circuit reduction voltage |
≤0.26V |
Discharge circuit reduction voltage |
≤0.15V |
temperature compensation |
-5mv/'C/2V |
Working temperature |
-35'C~55'C |
Control Type |
PWM |
Function |
Timer and light Controlled |
Fit for |
Solar Home System,Solar Energy system,Solar Light, Solar Garden Light, Solar Power Supply etc |
Warranty |
One-year quality warranty |
Feature:
Using MOSFET Control Switch, Switching speed and low-power consumption, high-conversion efficiency.
Using Digital opt coupler circuits and control circuits, and strong anti-interference.
Complete protection: short circuit protection; reverse current protection; reverse polarity protection; lightning protection; ;overcharge protection ;overdischarge protection etc
System designed to reduce pressure loaded, no-load loss.
LED displays the relevant parameters of solar charge controller and work status.
Convenient wiring, simple installation without Day-to-day maintenance, service life is up to 20 years
Display:LCD
Dimension: 140×90×26mm
Weight: 0.25KG
