Solar Charge Controller for Stret Light and Systems PETC-K01
This controller is designed for solar energy power dc supply system,and dc street lamps system, using special computer chip intelligent controller. A key type touch switch, complete all operations and Settings. It is with short circuit,overload and unique prevent inversed-connection protection,all protection measure such as automatic shutoff when full charging and overdischarging, recover automaticlly.detailed indicator of charging,overload,shoottrouble ect. This controller get samples on the battery voltage, discharging current, the environment temperature and the parameters of battery through computer chips ,through the special control model calculation, realizing the control high accuracy and efficiency of the discharge rate, storage temperature compensation which is line with the battery, and the high-efficiency charging pattern- PWM, ensure the best job in the state, extend battery life greatly. It has a variety of work mode, output model selection, satisfy customer all kinds needs.
Technical parameters
Items |
Solar Charge Controller
|
Model |
EPRC - 5LED – W EPRC - 10LED - W |
Rated Charge Current |
5A, 10A(12V/24V Auto) |
Rated Load Power |
5A Rated Voltage:12V:≤50W Rated Voltage:24V:≤100W 10A Rated Voltage:12V:≤100W Rated Voltage:24V:≤200W Note:Depend on the power of LEDs |
Constant power control precision |
>5% |
Overload, short circuit protection |
1.25 times rated current 60 seconds. 1.5 times rated current 5 seconds overload protection. |
System Voltage |
12V/24V Auto |
No-load Consumption |
≤6mA |
Recharge circuit reduction voltage |
≤0.26V |
Discharge circuit reduction voltage |
≤0.15V |
Overpressure protection |
17V,×2/24V |
Ascending recharging voltage |
1.46 V, X 2/24V, Time 10min,(only when the discharge calls) |
Balanced recharging voltage |
14.4 V, X 2/24V, Maintain time:10min |
Floating charging |
13.6 V, X 2/24V, maintain Time: (until) voltage recharge returns |
Charging return volatage |
13.2v; ×2/24V(ascension, straight, floating and charging returns voltage compensation), |
Overcharging return volatage |
12.6 V, X 2/24V |
Out of volatage |
12.0V; ×2/24V; |
Overdischarge voltage |
11.1 V - the discharge rate consumpution initial Overdischarge voltage (no-load voltage), X 2/24V, |
temperature compensation |
-5mv/°C/2V |
Working temperature |
industry-specific:-35°C~55°C(suffix I) |
Control Type |
charging :PWM pulse width modulation, output :Constant power |
Function |
Timer and light Controlled |
Fit for |
Solar Home System,Solar Energy system,Solar Light, Solar Garden Light, Solar Power Supply etc |
Warranty |
One-year quality warranty |
Features:
1 Intelligent control. Specially designed for the constant power control output for LED light source, more advanced than output ways of constant-current control , more efficient , control conversion efficiency can reach above 90%. And can output power through the setup and fine-tune LED light source . At the same time,it can achieve half power (-TH) of timing , or adjust LED light source output power (- A) automaticlly according to the actual power of the battery , greatly improving the supply power rate of system. (also can realize constant current output control).
2,Soft start-up function and continuous stepless adjustment light function.
3, Fixed accurate discharge control by using discharge rate features of battery . the discharge end voltage is the control point which is fixed by discahrge rate curve ,eliminating the inacurate of the pure control to the valtage overdischarging, according with the inherent characteristics of battery namely different discharge rate has different end voltage.
4 Complete protection:fully automatic control and protection of overcharging,overdischarging,short circuit ,overload,unique counter-attack connect ,reverse current ,reverse polarity,lightning etc. All above protection without causing damage to any component, not burning insurance.
5 Tandem PWM charging main circuit,can reduce the 50% loss of the charging circuit than using diode recharging circuit ,charging efficiency is 3% - 6% higher than non-PWM , increased the using power time, Ascending charging after overdischarging restore, normal balance charging, floating charging of automatic control mode can extend battery life, high precision temperature compensation.
6 LED displays the relevant parameters of solar charge controller and work status.,
7 All control use industrial chip (only to suffix I-industry-specific controller), operation free in high temperature, moisture environment . Use crystals timing control ,realize accurate timing control.
