Help CenterStandard Plain/ Flat Ceiling t Grid / Tee Bars/t Bar for False Ceiling
Related Products
-
GOOD Sell Price!! T Bar&t Grid Suspended Ceiling Grid Are Factory Direct SaleUS$ 0.1 - 1.2MOQ: 25 Tons -
Suspending Ceiling T-GridUS$ 0.1 - 1MOQ: 25 Tons
-
Cheap Chinese T-grid Tee BarUS$ 0.1 - 1MOQ: 25 Tons
-
T-grid, T-bar on Sale Cheapest Price Good QualityUS$ 0.1 - 1MOQ: 25 Tons
-
Cheap High Quality Main Tee Cross Tee Wall AngleUS$ 0.1 - 1MOQ: 25 Tons
Product |
Size(mm) |
Package |
Quantity/square meter |
Main Tee |
32*24*3600/3660 |
27PCS/CTN |
0.81M |
38*24*3600/3660 | |||
Cross Tee |
26*24*1200/1220 |
75PCS/CTN |
1.62M |
32*24*1200/1220 | |||
Cross Tee |
26*24*1200/1220 |
75PCS/CTN |
0.81M |
32*24*1200/1220 | |||
Angle |
22*19*3000 |
50PCS/CTN |
0.6M |
|
22*22*3000 |
Parameters details
Raw material:hot dipped galvanized steel
Thickness:0.3mm-1.0mm
Surface treatment :GI/ Galvanized
Zinc coating: 50-275g/m2
Packing: seaworthy standard export packing methods
Technic: hot dipped cold rolled
Introduction of products:
The raw material of light steel keel/profile/frame/channel or light weight metal frame, galvanized steel profile is high-quality hot dipped zinc galvanized steel strip:
1. Zinc coating up to 50-275g/m2 or even more, which contains the advantages of high rust resistance, longer working lifetime, damp proof, heat insulation, good durability.
2. We have expanded our markets to Southeast Asia,Middle East , Africa , Oceania , Eastern Europe ,and America.
3. Specifications can be customized flexibly according to your requirements.
4. With workers having a great wealth of experience and well-maintained U/C roll forming machines, our products and services have gained an excellent reputation.
| 1. Specification of South America market | |||
| Partition | |||
| Commodity | Specification (mm) | Thickness(mm) | Length(mm) |
| Stud | 41*32 | 0.4--1 |
8FT--10FT 2440--3050 |
| 64*32 | |||
| 76*32 | |||
| 92*32 | |||
| 92*41 | |||
| 100*35 | |||
| Track | 41*25--40 | 0.4--1 |
8FT--10FT 2440--3050 |
| 64*25--40 | |||
| 76*25--40 | |||
| 92*25--40 | |||
| 100*25--40 | |||
| Corner bead | 32*32 | 0.3--0.7 | 8FT--16FT 2440--4800 |
| Ceiling | |||
| Component name | Specification (mm) | Thickness (mm) | Length |
| Main channel | 38*12 | 0.4--0.8 |
8FT--16FT 2440m--4800m |
| 37*20 | |||
| Furring channel | 58*34*16 | ||
| 64*32*22 | |||
| 47*17 | |||
| 52*25*15 | |||
| 2. Specification of Malaysia market | |||
| Partition | |||
| Commodity | Specification (mm) | Thickness (mm) | Length (mm) |
| U channel | 41*23 | 0.3-0.5 | 2440, 2740, 3050 |
| 44*22 | |||
| 48*22 | |||
| 50*23 | |||
| 75*24 | |||
| Roof and Ceiling | |||
| Commodity | Specificaion (mm) | Thickness (mm) | Length (mm) |
| C section | 75*34*36 | 0.7--1 | 3660---5800 |
| 100*50 | |||
| Batten | 58*35*23 | 0.5--0.8 | 3660--5800 |
| 65*32*26 | |||
| 84*30*32 | |||
| Furring Channel | 30*9 | 0.25--0.4 | 3050--4880 |
| 34*11 | |||
| 3)Specification of Middle East market | |||
| Partition | |||
| Commodity | Specification (mm) | Thickness (mm) | Length (mm) |
| Stud | 50*35/40 | 0.4--1 | 3000 |
| 70*32/35 | |||
| 75*35/40 | |||
| 100*35 | |||
| Track | 50*25--50 | 0.4--1 | 3000 |
| 70*25--50 | |||
| 100*25---50 | |||
| Ceiling | |||
| Commodity | Spceification (mm) | Thickness (mm) | Length (mm) |
| Main channel | 38*10--12 | 0.38--0.5 | 3000 |
| Furring channel | 64*32*22 | ||
| 70*35*22 | |||
| 80*48*22 | 0.7 | 4000 | |
| 4. Specification of Eastern Europe market | |||
| Partition | |||
| Commodity | Specification (mm) | Thickness (mm) | Length (mm) |
| Stud | 50*50 | 0.4--0.7 | 3000 |
| 75*50 | |||
| 100*50 | |||
| Track | 50*25--50 | ||
| 75*25--50 | |||
| 100*25--50 | |||
| Ceiling | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| Furring channel | 60*27 | 0.5--0.7 | 3000 |
| Wall angle / Track | 28*27 | 0.5--0.7 | 3000 |
| 5. Specification of Myanmar market | |||
| Partition | |||
| Commodity | Specification (mm) | Thickness (mm) | Length (mm) |
| Stud | 75x35 | 0.4--0.6 | 3000 |
| 65x32 | |||
| Track | 76x25 | ||
| 66x25 | |||
| Roof and Ceiling | |||
| Commodity | Specification (mm) | Thickness (mm) | Length (mm) |
| C sectionC section | 75x34x36 | 0.7--1.5 | 5800 |
| 100x50x50 | |||
| BattenBatten | 64x24x24 | 0.4--0.6 | 5800 |
| 65x32x26 | |||
| Furring channel / C-line | 35x12 | 0.3--0.5 | 3960 |
| Main channel | 18x28 | 0.5--0.8 | 3050 |
| Furring channel | 50x17 | 0.4-0.5 | |
| 6. Specification of Thailand market | |||
| Partition | |||
| Commodity | Specification (mm) | Thickness (mm) | Length (mm) |
| Stud | 75x35 | 0.4--0.55 | 2400, 3000 |
| 65x32 | |||
| Track | 76x25 | ||
| 66x25 | |||
| Roof and Ceiling | |||
| Commodity | Specification (mm) | Thickness (mm) | Length (mm) |
| C section | 75x34x36 | 0.7-1.5 | 6000 |
| 100x50x50 | |||
| Batten | 65x25x26.5 | 0.4-0.6 | |
| 65x32x26 | |||
| Furring channel / C-line | 35x12 | 0.3-0.5 | 4000 |
| 7.Specification of Philippines market | |||
| Partition | |||
| Commodity | Specification (mm) | Thickness (mm) | Length (mm) |
| Stud | 50*32 | 0.4--0.8 | 3000 |
| 64*32 | |||
| 75*35 | |||
| 92*35 | |||
| 100*35 | |||
| Track | 50*25--50 | 0.4--0.8 | 3000 |
| 64*25--50 | |||
| 75*25--50 | |||
| 92*25--50 | |||
| 100*25--50 | |||
| Roof and Ceiling | |||
| Commodity | Specification (mm) | Thickness (mm) | Length (mm) |
| C section | 100*50 | 0.7--1.5 | 3000 |
| 150*50 | |||
| Main channel | 38*12 | 0.5--0.8 | 3000 |
| Furring channel | 50*19 | 0.4--0.5 | 3000 |
| 8. Specification of Ausralia market & New Zealand | |||
| All Australia products make with high quality galvanized metal with zinc coating 275g/m2 | |||
| Partition | |||
| Component name | Specification (mm) | Thickness (mm) | Length (mm) |
| Stud | 51x33.5x35.5 | 0.5--0.75 | 2400-3600 |
| 64x33.5x35.5 | |||
| 76x33.5x35.5 | |||
| 92x33.5x35.5 | |||
| Track | 52x32/28 | 0.5--0.75 | 3000 |
| 65x32/28 | |||
| 77x32/28 | |||
| 93x32/28 | |||
| MPW 10 H Stud | 12.5X40 | 0.3-0.5 | 3000-6000 |
| MPW 10 H Stud | 25X35 | ||
| MPW 10 U Kap | 15X25 | ||
| MPW 10 π Track | 55X25 | ||
| V-Corner bead | 30X30 | ||
| L -Corner bead | 30X6 | ||
| L-Corner bead | 30X10 | ||
| L -Corner bead | 30X13 | ||
| L -Corner bead | 30X16 | ||
| J -Corner bead | 30X10X13 | ||
| Z -Corner bead | 30X10X10 | ||
| Z -Corner bead | 30X10X6 | ||
| Roof and Ceiling | |||
| Commodity | Specification (mm) | Thickness (mm) | Length (mm) |
| Top cross rail | 25x21 | 0.55/0.75 | 3600,4800,6000 |
| Furring channel | 51x38x28 | 0.5 | 2700,3000,4800,6000 |
| 51x38x16 | |||
| C channel | 36x16 | 0.45 | 3000,3600 |
| Wall angle | 35x16x13 | 0.5 | 3000 |
| 35x28x20 | |||
| Batten | 94x42x40 | 0.55/0.75 | 4800,6000 |
Company and Factory:
Point 1:Quality is absolutely guaranteed no matter when. Products are highly galvanized up to 275g/ m2 and made strictly according to international standards, no matter for the durability test ,tensile strength test and so on.
Point 2: Price is the lowest because the factory is not only in the steel base of china, LangFang, Heibei, but also in the Free Trade Area, so we can enjoy the preferential policy concerning export. Also we have a large workshop of 40,000 square meters.
Point 3: We do our best to offer the first-line service, we are very careful with packing methods and the delivery time. We hope every client can have a pleasant experience here.
2015 SPRING CANTON FAIR
Our company tenets:
1. Products are for sale only after passing through comprehensive testings.
2. All products are designed stylishly, with innovation and ease of installation.
3. Quality and safety always come first.
Contact information:
Name: Vivian
Tel: 86 20 8746-8918
Fax: 86 20 8746-9339
Skype: Duan Vivian(from Guangzhou, China)
QQ:3332434936
Facebook: Wei Wei/ 18273172149
OFFICE ADD:B402,NO.8 KESHENG ROAD,
PRIVITAL HIGH-TECH INDUSTRY ZONE,BAIYUN DISTRICT,GUANGZHOU CITY(510540),CHINA.
Guangzhou Jianli New type Partition Co.Ltd.
Offical website : www.
