The controller board for digital TV / Analog TV ,support DTV (DVB-T) H.264 format/SCART IN/ OUT/NICAM/Teletxt/SPDIF/HDMI/USB

Specifications

The TV board if suitable for analog TV system PAL/SECAM, Compatible SAMSUNG, CMO, AU, LGP , SHARP and BOE market .

Suitable for analog TV system PAL/SECAM
Compatible SAMSUNG, CMO, AU, LGP and SHARP
The main IC adopt the MSTAR single chip MSD309 program
Maximum supports FULL HD resolution up to 1920 x 1200 TFT-LCD screen and 1 VGA interface
Supports 1,920 x 1,200 @60Hz input 1 AV input and analog HD input
Analog high definition interface signal input max supports 1080P format
One and HDMI 1.3A, HDCP 1.2 and DVI 1.0.One &USB interface
Supports audio (MP3/WMA), video (AVI RM RMVB MPEG 1 to 4 h.264), picture (JPEG, BMP PNG), dynamically adjust the image color, contrast, definition, brightness,  chroma transient improvement function, black/white level extensions, color compensation function
Supports for bass and treble control, stereo input, audio amplifier output rate power 3W x 2 (80hm) amplifier
Input video format auto-detection
Reliable EMC and treatment measure of anti-static
