Home > Products > TV board > 8-core 2G DDR 8G / 16G / 32G Storage RJ45 Serial Port All-in-one Android AD Controller Board
8-core 2G DDR 8G / 16G / 32G Storage RJ45 Serial Port All-in-one Android AD Controller Board
- 10000 Piece / Pieces per Month
- Hongkong
- Digital thermometer hygrometer used for travelling weather station pocket type
- Wireless Atomic Table Clock, Thermometer/Display In/Out Temperature, Blue/Green Backlight Selectable
- Weather Station Clock with Forecast/Desk/Digital Clock with in/Outdoor Temperature and Humidity
- Wired Weather Station/Desk/Digital Clock with In/Outdoor Temperature Display
- MAX / MIN Temperature And Humidity Automatic Memory Digital Thermometer Hygrometer
- Atomic Projection Desk Clock with Indoor Temperature and Big Character Display
Product Details
Place of Origin: | Guangdong, China | Brand Name: | CND | Model Number: | YF-A83T-070AD |
Type: | TFT |
Product Description
Product Name: 8-core 2G DDR 8G / 16G / 32G Storage RJ45 Serial Port All-in-one Android AD Controller Board
Model No.: YF-A83-070AD
General Descritpion
YF-A83-070AD Board is an integration of Multi-media Decoding, LCD Panel Driver, Ethernet, HDMI, WIFI, Audio Amplifier. It supports decoding almost all format of the popular Video and Image. Besides, it supports HDMI output, and is compatible with all type of TFT LCD Panel. It dramatically simplifies integral machine design. It is suitable for HD network play box, video advertising Machine, Photo-frame Advertising Machine.
Key Features
- High Integration: Integrated with USB LVDS Ethernet HDMI WIFI, All-in-one, Simplifies Integral Machine design, with TF card slot.
- Android 4.4.4 Operation System, 1G/2G DDR, EMMC8G/16G / 32 (Options)
- High Resolution: Supports 1080P/H.265(4K2K) Video decoding and various LVDS output LCD Display Screen.
- With Audio Amplifier: Supports Dual channel amplifier 8R/10W.
- Rich Interfaces: Support USB, Serial Port, GPIO, ADC, suitable for mainstream AD machine in the market.
- Full Function, Support display screen both landscape and portrait, Video split screen, rolling word screen, On/Off Timing,Data Transfer through USB.
- Easy Management:Humanization software for playlist making, for advertising-display management and control easily. With advertising-display record, which make it easy to check AD display status.
Hardware specification | |
CPU | All Winner A83T , 8-core,Frequency 1.8 GHz |
Flash | 1G LPDDR3 (Option 2G) |
Inner storage | EMMC 8G / 16G / 32G (option) |
Decoding Resolution | Up to 1080P/H.265 |
OS | Android 4.4.4 |
Display Mode | Support Recycling, timing, inserting play mode |
Internet Interface | Ethernet, WIFI,Wireless Extending |
Video Format | Support wmv,avi,flv,rm,rmvb,mpeg ,ts,H.265,mp4 |
Image Format | Support BMP,JPEG,PNG,GIF etc. |
USB2.0 | 2 way USB HOST |
Ethernet | 1 way,10M/100M Adaptive Ethernet |
LVDS Output | Dual channel,can drive LCD Panel 50/60Hz |
HDMI Output | 1way ,support up to 1080P output |
Audio Out | Right/Left Sound Channel 8R/10W loudspeaker |
RTC | Support |
Hardware watch-dog | Support |
Timer on/off | Support |
System Upgrading | Support USB/ TF card / Internet |
One Year Quality Warranty;
Provide 1‰ free spares with all goods;
Flexible Software to meet any custom request;
Q: Who we are? what's our Brand?
A: We are CND Electronic Technology (ShenZhen) Co., Ltd.
is our registered Brand.
Q: Where are you located? How can I get there?
A: Our office is in Shekou Nanshan Shen Zhen, very close to ShenZhen Bay. it takes just 0.5h from HK to ShenZhen Bay.
Q: What's delivery time? what's the shipping methord?
A: 3 days for some items in stock; and 15 days if out of stock, shipment via sea or air as customer requested.
Q: What's our core product and services?
A: AD/ AV Board, LCD / LED TV main controller driver board Solution, LCD Monitor main Driver Controller Solutions
Q: What are our product applied in, and who is our Customer?
- Touch-Screen ATM Display of BOC (Bank of China), CBC (Contruction Bank of China), ABC, etc
- Mobile-TV of High-speed Railway Train for CRRC, and for subway train;
- Monitors of industrial control, for instance Security-montoring
- Monitors of some Famous Chinese Brand, for example HKC, AOC, ViewSonic, etc.
Q: What are our capability and advantages?
- CND is the only AD board solution company whose 2K board have been sold more than 100K.
- CND is the first company developed UHD 4K board solutions.
- CND is the first one who have passed Freesync Cetification.
- CND is the first one developed Type-C 4K *2K board.
- Integrated PQ services, including GAMMA, OD, AdobeRGB 100%, free sync dynamic OD, FPS/RTS precise color...
- Integrated Customization sevices from OSD/LOGO, PC OSD Menu, Uart extension, IR extension
CND is the best choice for LCD / LED main board solutions, with over 10 years professional experiences both in hardware and software design, she has gained very good reputation during cooperation with biggest clients from financial , rail transit, and industrial etc. Quality is our culture, Time is gold, Service is our soul, to be with us your business is safe, your money is safe choose CND, choose a mutual win-win partner.
