Bus LCD Monitor Display Driver Controller Main Card With HDMI VGA USB 2*AV Support Flip Image

Bus LCD Monitor Display Driver Controller Main Card With HDMI VGA USB 2*AV Support Flip Image thumbnail-1
Bus LCD Monitor Display Driver Controller Main Card With HDMI VGA USB 2*AV Support Flip Image thumbnail-2
Bus LCD Monitor Display Driver Controller Main Card With HDMI VGA USB 2*AV Support Flip Image thumbnail-3
Bus LCD Monitor Display Driver Controller Main Card With HDMI VGA USB 2*AV Support Flip Image photo-1
Bus LCD Monitor Display Driver Controller Main Card With HDMI VGA USB 2*AV Support Flip Image photo-2
Bus LCD Monitor Display Driver Controller Main Card With HDMI VGA USB 2*AV Support Flip Image photo-3
US$ 8 - 11 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CND
Model Number:
AVX9-cz
Contact Supplier Request Quote Chat Now
CND Electronic Technology (Shenzhen) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name CND
Model Number AVX9-cz

             Bus LCD Monitor Display Driver Controller main Card with HDMI VGA USB 2*AV support Flip Image

1.General description

AVX9  board is compatible with LCD panel of mainstream manufacturers,Such

as SUMSUNG,CMO,AU.LGP,SHARP.,BOE and so on.  It can support less than

 26 inch LCD panels which resolution is up to 1920×1080.





2.Feature

. LCD computer motherboard with vga hdmi usb



.Working voltage:+12V



.OSD language:English, French, German, Italian, Spanish, Portuguese,



.Standby Power Consumption < 0.3W



.Support USB firmware upgrade and media player function





.HDMI  VGA USB 2*AV



. Single/Dual Channel LVDS



. Supporting up to1920*1080 resolution



Bus LCD Monitor Display Driver Controller main Card with HDMI VGA USB 2*AV support Flip ImageBus LCD Monitor Display Driver Controller main Card with HDMI VGA USB 2*AV support Flip Image



specification :

IC TSUM39LU(can choseTSUM29LU)
OSD language English , French , German, Italian, Spanish , Portuguese
Match panel resolution Max.:1920X1080
interface Single/dualLVDS
voltage 3.3V,5V,12V
Input signal computer

Signal RGB(0.7Vp-p),Synchronous separation
line (TTL)
video Color sytem PAL/SECAM/NTSC
Video range 1.0 Vp-p ±5%
Audio Earphone input 0.2 – 1.5 Vrms
Output signal Audio consumption:3W * 2 THD+N<10%
socket:4Pin/2.0mm space
Control key

STANDARD SEVEN KEY:POWER/MENU/INPUT OPTION/CH+/CH-/VOL+/VOLCompatible
five key
OSD menu:

Brightness, Contrast, Auto-correction, Horizontal &field position,
Function set, Color system, Language, Background, Noise reduction

Power supply
input:

 4pin 2.0mm socket or 12V DC socket





.

 Usage

 This wide range temperature A/D board is designed for industrial, marine and military grade LCDs. Its wide operational temperature range (-40 ~+80°C) can meet the requirements of the harsh ambient environments. It supports resolution from 640*480@60Hz up to 1920*1200@60Hz. This board has been applied to drive Mitsubishi, AUO, NEC LCD panels.

Bus LCD Monitor Display Driver Controller main Card with HDMI VGA USB 2*AV support Flip ImageBus LCD Monitor Display Driver Controller main Card with HDMI VGA USB 2*AV support Flip Image



Our Services

One Year Quality Warranty;

Provide 1‰ free spares with all goods;

Software Services;

Application:

Bus LCD Monitor Display Driver Controller main Card with HDMI VGA USB 2*AV support Flip Image



Company Information

CND RD TeamBus LCD Monitor Display Driver Controller main Card with HDMI VGA USB 2*AV support Flip Image

Quality Assurance

Bus LCD Monitor Display Driver Controller main Card with HDMI VGA USB 2*AV support Flip Image

Workshop and equipments

Bus LCD Monitor Display Driver Controller main Card with HDMI VGA USB 2*AV support Flip Image

CND Certificates: ISO, Patent, Hi-Tech

Bus LCD Monitor Display Driver Controller main Card with HDMI VGA USB 2*AV support Flip Image

FAQ

Q:  Where are you located? How can I get there?

A: Our office is in Shekou Nanshan Shen Zhen. It's very close to ShenZhen Bay.  it takes just 0.5h from HK to ShenZhen Bay.



Q: We are using several panel. how to match and change the software?

A: Our software supports panel select by jumpet hat.  no need change software for different panel.



Q:  What's delivery time? what's the shipping methord?

A: 15 days delivery time after get depositb. we are 100% be sure delivery on time. we can accept shipment via sea or air as customer requested.

Q: Who we are?  what's our Brand?

A:We are CND Electronic Technology (ShenZhen) Co., Ltd.

Bus LCD Monitor Display Driver Controller main Card with HDMI VGA USB 2*AV support Flip Image is our registered Brand.

Q: What's our core product and services?

A: AD/AV Board, LCD / LED TV main controller driver board Solution, LCD Monitor main Driver Controller Solutions

Q:  What are our product applied in, and who is our Customer?

A: by far, our AD board solutions have applied in:
      1. Mobile-TV of High-speed Railway Train for CRRC, and for subway train;
      2. Touch-Screen ATM Display of BOC (Bank of China), CBC (Contruction Bank of China), ABC, etc
      3. Monitors of industrial control, for instance Security-montoring
      4. Monitors of some Famous Chinese Brand, for example HKC, AOC, ViewSonic, etc.


Q: What are our capability and advantages?

A: We've proud that
      1. CND is the only AD board solution company whose 2K board have been sold more than 100K. and
      2. We're the first company developed UHD 4K board solutions.
      3.CND is the first one who have passed Freesync Cetification.
     4. CND is the first one developed Type-C 4K *2K board.
     5. Integrated PQ services, including GAMMA, OD, AdobeRGB 100%, free sync dynamic OD, FPS/RTS precise color...

     6. Integrated Customization sevices from OSD/LOGO, PC OSD Menu, Uart extension, IR extension









Bus LCD Monitor Display Driver Controller main Card with HDMI VGA USB 2*AV support Flip Image is the best choice for LCD/LED main board solutions, with over 10 years professional experiences both in hardware and software design, she has gained very good reputation during cooperation with biggest clients from financial , rail transit, and industrial etc. Quality is our culture, Time is gold, Service is our soul, to be with us your business is safe, your money is safe choose CND, choose a mutual win-win partner.
