Plain Galvanized Platform 1*5.8M Grating (smooth Surface)

US$ 5 - 55 MOQ: 50 Square Meters

Key Specifications

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Grade:

Iron

Dimensions:

G255/30/100

Hebei Jiuwang Metal Wire Mesh Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xingang

Delivery Detail:

Delivery time depends on order quantity.

Standard AISI, ASTM, BS, DIN, GB, JIS

Grade Iron

Dimensions G255/30/100

Place of Origin Hebei, China

Brand Name JW

Model Number Q235

Type Light

Application Steel Structure Platform

Plain galvanized platform 1*5.8M grating:

Product details:

Model No.	G255/30/100
Bearing bar thickness (mm)	5
Bearing bar width (mm)	25
Cross bar diameter (mm)	6
Bearing bar pitch/distance (mm)	30
Cross bar pitch/distance (mm)	100
Surface treatment	galvanized
Standard	China: YB/T4001.1-2007 UK: BS4592-1-1995 USA: ANSI/NAAMM(MBG531-88) Australia: AS1657-1985
Certificate	ISO9001

Other details:

Package	Safety package or naked
Delivery	Within 20-30 days after receiving the deposit
Payment terms	EXW: 100% T/T. FOB: T/T, 30% deposit, 70% balance payment before shipping. CIF: T/T, 30% deposit, 70% balance payment at the sight of copy of B/L.
HS code	7308900000

Common sizes of steel grating:

Bearing Bar Spacing	Cross Bar Spacing	*Bearing Bar Specification ( Width Thickness)**
( mm )	( mm )	*203 ( mm )**	*253( mm )**	*323( mm)**	*403( mm )**	*205( mm )**	*255( mm )**
30	100	G203/30/100	G253/30/100	G323/30/100	G403/30/100	G205/30/100	G255/30/100
	50	G203/30/50	G253/30/50	G323/30/50	G403/30/50	G205/30/50	G255/30/50
40	100	G203/40/100	G253/40/100	G323/40/100	G403/40/100	G205/40/100	G255/40/100
	50	G203/40/50	G253/40/50	G323/40/50	G403/40/50	G205/40/50	G255/40/50
60	50	G203/60/50	G253/60/50	G323/60/50	G403/60/50	G205/60/50	G255/60/50
