Circle Steel Grating With Hole ISO 9001 WITH 20years Factory

Name: Circle Steel Grating With Hole ISO 9001 WITH 20years Factory
Brand: JIUWANG
SKU: 134029319
Availability: InStock

Circle Steel Grating With Hole ISO 9001 WITH 20years Factory thumbnail-1

Circle Steel Grating With Hole ISO 9001 WITH 20years Factory photo-1

US$ 10 - 30 MOQ: 10 Square Meters

Key Specifications

Get Latest Price

Place of Origin:

Hebei, China

Brand Name:

JIUWANG

Model Number:

19-W-4; 15-W-2,12.5/25/30/32.5/35/40/50mm.etc

Contact Supplier Request Quote Chat Now

Hebei Jiuwang Metal Wire Mesh Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjin

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hebei, China

Brand Name JIUWANG

Model Number 19-W-4; 15-W-2,12.5/25/30/32.5/35/40/50mm.etc

Material Other, Steel, carbon steel,stainless steel

Specifications

1.circle steel grating with hole
2. tenstile &corrosion
3.beautiful surface
4.hot dipped galvanized
5.ISO9001

circle steel grating with hole

circle steel grating with hole is to produce a variety of irregular shapes based on actual customer demand steel grating, mainly cutting angle, cutting holes, cut arcs, sectors, so as to avoid further cutting the goods to the secondary site, thereby make more rapid construction and installation, with simple, but also to avoid damaging the scene cut galvanized layer. Shaped steel grating is relatively rectangular grating purposes.

2.materials types

3. circle steel grating with hole WEIGHT SPECIFICATIONS :

Bearing bar pitch	Cross bar pitch	load steel size ( Width ×Thickness)
Bearing bar pitch	Cross bar pitch	20×3	25×3	32×3	40×3	20×5	25×5
30	100	G203/30/100	G253/30/100	G323/30/100	G403/30/100	G205/30/100	G255/30/100
30	50	G203/30/50	G253/30/50	G323/30/50	G403/30/50	G205/30/50	G255/30/50
40	100	G203/40/100	G253/40/100	G323/40/100	G403/40/100	G205/40/100	G255/40/100
40	50	G203/40/50	G253/40/50	G323/40/50	G403/40/50	G205/40/50	G255/40/50
60	50	-	G253/60/50	G253/60/50	G403/60/50	G205/60/50	G255/60/50
Bearing bar pitch	Cross bar pitch	load steel size (Width ×Thickness)
Bearing bar pitch	Cross bar pitch	32×5	40×5	45×5	50×5	55×5	60×5
30	100	G325/30/100	G405/30/100	G455/30/100	G505/30/100	G555/30/100	G605/30/100
30	50	G325/30/50	G405/30/50	G455/30/50	G505/30/50	G555/30/50	G605/30/50
40	100	G325/40/100	G405/40/100	G455/40/100	G505/40/100	G555/40/100	G605/40/100
40	50	G325/40/50	G405/40/50	G455/40/50	G505/40/50	G555/40/50	G605/40/50
60	50	G325/60/50	G405/60/50	G455/60/50	G505/60/50	G555/60/50	G605/60/50

Steel Grating Standard
	Steel Grating Standard	Steel Standard	Galvanizing Standard
China Standard	YB/T 4001.1-2007	GB700-88	GB/T13912-2002
USA Standard	ANSI/NAAMM (MBG531)	ASTM (A36)	ASTM (A123)
U.K. Standard	BS4592	BS4360 (43A)	BS729
Australia Standard	AS1657	AS3679	AS1650
Deutsche Standard	DIN24537	DIN17100-80	DIN50976

Package	Safety package or naked
Delivery	Within 15-20 days after receiving the deposit
Payment terms	EXW: 100% T/T. FOB: T/T, 30% deposit, 70% balance payment before shipping. CIF: T/T, 30% deposit, 70% balance payment at the sight of copy of B/L.
HS code	7308900000
Price validity	Within 7 days

4. circle steel grating with hole Features assembly is circular, trapezoidal, semi-circular, fan-shaped; firmly welded mesh to have a high load, the structure is light, easy loading and other characteristics; appearance, durable. Can be customized according to user requirements, customers can design and installation.

5. circle steel grating with hole Application: alloy, building materials, power plants, boilers. Shipbuilding. Petrochemical, chemical and general industrial plants, municipal construction and other industries, with air and light, non-slip, bearing capacity is strong, beautiful and durable, easy to clean, easy to install and so on. Steel grating has been widely used in all walks of life at home and abroad, mainly used for industrial platforms, ladders pedal, railings, access flooring, railway bridge side road, aerial tower platform, gutter covers, manhole covers, road grille, three-dimensional parking, offices, schools, factories, enterprises, stadiums, garden villas fences, can also be used, balcony guardrail, highway, railway fence Bed outer windows.
