Platform Steel Grating(ISO 9001:2000)
US$ 75 - 255
MOQ: 1500 Square Meters
Key Specifications
Get Latest Price
Standard:
AISI, ASTM, BS, DIN, GB, JIS
Grade:
carbon steel and stainless steel
Dimensions:
35x3
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Ansi/NAAMM ( MGB 531-88 )welding Steel GratingUS$ 19.3 - 90MOQ: 420 Square Meters -
Steel Grating Platform Usd in Construction ProjectNegotiableMOQ: 5 Square Meters
-
Packed Platform Metal Bar Grating (Platform Bar Grating)US$ 5 - 28MOQ: 500 Square Meters
-
Platform Steel GratingNegotiableMOQ: 5 Square Meters
-
Ohio Steel Grating (Chinese Manufacture)US$ 5 - 25MOQ: 10 Square Meters
Standard
AISI, ASTM, BS, DIN, GB, JIS
Grade
carbon steel and stainless steel
Dimensions
35x3
Place of Origin
Hebei, China
Brand Name
JW
Model Number
35x3
Type
Light
Application
Steel Walkway And Floor
Specifications
1. Full range of steel gratings.2. 4 running lines with more than 20,000 tons per year.
3. ISO9001:2008 quality system
4.ISO
Detail Descreption of walkway grating/platform steel grating/flooring steel grating/drain cover/trench cover/stair tread/bar grating/grates/painting steel grating.
1> Material: Carbon steel or stainless steel grating
2> Bearing bar specification: 20 × 3mm to 90× 7mm
3> Bearing bar pitch: 12.5, 15, 25, 30, 40, 60mm etc. Also be according to clients requirement and 30, 40, 60mm are recommended
4> Cross bar pitch: 50, 100mm are recommended
5> Maximum length of black panel: 6, 100 mm
6> Surface treatment: Untreated, paint or hot dip galvanized
7> Steel grating standards:
A) China: YB/T4001-1998
B) USA: ANSI/NAAMM (MBG531-88)
C) UK: BS4592-1987
D) Australia: AS1657-1985
| Item No. |
Bearing Bar Pitch |
Cross Bar Pitch |
Specification of bearing bar load( width × thickness ) | |||||
| 20× 3 | 25× 3 | 32× 3 | 40× 3 | 20× 5 | 25× 5 | |||
| 1 | 30 | 100 | G203/30/100 | G253/30/100 | G323/30/100 | G403/30/100 | G205/30/100 | G255/30/100 |
| 50 | G203/30/50 | G253/30/50 | G323/30/50 | G403/30/50 | G205/30/50 | G255/30/50 | ||
| 2 | 40 | 100 | G203/40/100 | G253/40/100 | G323/40/100 | G403/40/100 | G205/40/100 | G255/40/100 |
| 50 | G203/40/50 | G253/40/50 | G323/40/50 | G403/40/50 | G205/40/50 | G255/40/50 | ||
| 3 | 60 | 50 | G253/60/50 | G253/60/50 | G403/60/50 | G205/60/50 | G255/60/50 | |
