GST02 high resolution gps vehicle tracker integrated fuel level sensor
- 360 Set / Sets per Month
- Tianjin Shanghai Qingdao
- T/T L/C D/P D/A Credit Card PayPal
- Fashionable Smart Personal Watch GPS Tracker with OLED Screen 108
- Smart GPS Watch Tracker/Personal GPS Tracker with Geo-Fence and Voice Talking for Children and Elder
- Manufacturer Wholesale 3G MINI Smart Watch GPS with Dual-Way Calling & SOS
- GPS Kids Mobile Watch with Dual-Way Calling & Sos / LBS GPS Tracking
- Best Selling GPS Kids Tracker with SIM Card Slot / LBS GPS Tracking Smart Watch for kids
- Kids Wrist Watch GPS Tracking Device / LBS GPS Tracking smart watch gps watch for kids
Product Details
Type: | Other, Gps Tracker, gps vehicle tracker | Use: | Automotive | Brand Name: | hengtop gps vehicle tracker |
Model Number: | GST02 gps vehicle tracker | Warranty: | 2 Years |
Product Description
GST02 high resolution gps vehicle tracker integrated fuel level sensor
Product feature of gps vehicle tracker
Fuel level detection for truck and non-road vehicle
High resolution and internal filter for fluctuation
Customized size to adopt fuel tank depth
Consist of high resolution capacitance level sensor and GPS
With hidden install type ,not easy to remove
Don’t need the cab ,just connect battery directly
Technical parameter of gps vehicle tracker
Working Power | DC12V/40mA(DC10V~DC32V) DC24V/30mA(DC20V~DC32V) |
Resolution | 0.01%FS |
Probe Resistance Temperature | -40~150°C |
Envrionment Temperature | -30~85°C |
Relative Humidity | 10%~95% |
Diameter | Ø16 |
Standby Battery | Lithium Battery 850mah |
Power Dissipation | Standby Current ≤40Mah Peaking Current≤70Mah |
Communication | GSM 900 Mhz Class4 2W/ GSM 1800 Mhz Class1 1W (Need set APN ) |
Satellite Module | 32 channel ,L1 waveband ,(1575.42 Mhz)C/A,-159DBM |
Position Accuracy | 10m |
Signal Refresh | 4 times /second |
Pressure Range | -0.1Mpa~0.1Mpa |
Material | Stainless Steel |
Anti-explosion | Exd II C T5 |
Protection Rank | IP68 |
Mounting | Flange |
Other Customized Service |
Detailed drawing of gps vehicle tracker
gps vehicle tracker practical application from customer
1.When need to use calibrator ?
After you cut it ,if you never cut it ,no need calibrate .
2.How to calibrate it ?
Press the full or empty button till the lamp flash one time ,release the button wait 5 seconds ,
then finish calibration .
3. Can I use it with gps tracker?
Yes, it support any gps tracker with 0-5v analog input RS232/RS485 input . If RS232 interface, the gps tracker need to do integration with our sensor protocol.
4. Which is the gps tracker list it support?
Any gps tracker with 0-5v analog input and RS232/RS485 input . such as A300, VT310, MVT400, MVT600 and etc.
5. What is the resolution?
0.1%FS. If multiple with section area, we can conclude the liter resolution, normally
less than 1 liter for vehicle tank.
6. Can we measure the liter changing with it?
Yes, create one map between level and liter, then can draw liter changing.
7. Why is it expensive than other floating sensor?
Because capacitance is more stable and higher resolution than floating sensor.
So do not compare with different type of sensor. Just compare with other capacitance sensor,
our will be the most cost-effective one.
8. Do you have support for integration with our application?
Yes, we have EE and SW engineers team to support for you with integration of our product.
9. Is it safe for using with gasoline?
Sure, we have ExtdIIT certification.
10. Can we cut short to adopt our tank?
No, it does not support user cutting short. We have another model FLS2-700 support customer free cutting .
Feedback from our customer
After sale service of gps vehicle tracker
