Applicable to | Vertical hinged door of all materials, opening two-way |
Door width | Less than 1400mm |
Door weight | Less than 150kg |
Working procedure | Opening signal→unlocking control→open→ brake the door→hold open→automatic close→buffer→lock |
Automatic opening angle | Adjustable one-way 90° |
Opening hold | Adjustable 0~30 seconds |
Opening rate | Adjustable 3~7 seconds |
Closing rate | Adjustable 3~7 seconds |
Remote-control functions | Cipher code wireless remote-control opening, remote-control closing |
Automatic protection against overloading | Applied, using an electronic sensing system to protect the circuit |
Intelligent protection against obstacle | Applied, using an automatic revolving door protection system |
Alarming against error | Unapplied |
Intelligent overheating protection | Applied, using an automatic electronic protection circuit |
Closing buffer | Applied |
Electric lock control | Applied |
Locking torque adjustment | Applied |
Opening buffer | Applied |
Power supply | AC220,AC14V |
Input power static/Maximum | 6W/45W average power |
Dimensions of the main engine | 340Length*200Height*80.5Thickness |
1.Our OW-180 automatic door operator can match with all kinds of entrance guard equipment like sensor,button,password device,videophone and etc.
2.Our this model have water-proof function.So you can install it outside or inside as your request.
3.It buried under ground,will not take up too much space.
4.It equipped with UPS power,and can run up to 5 hours after the electic cutted off.
5.Runs quitely,can be used for large hospital,senior office,hotal,show room and etc.
l National Invention Patent Product.
l Microcomputer controller using cutting-edge technology, can fast, accurate detection of door status(size,weight), set the best operating parameters, to maintain the best condition.
l A brushless electric motor with a big torque, service life and high efficiency is adopted. An electromagnet is added to the motor to help achieve a 100kg locking capacity when the door is braked still.
l The transmission gearbox is equipped with a worm wheel, an endless screw and spiral wheels to transmit the motion. It runs smoothly with a super-low sound.
l A remote-control point is equipped to help easily switch between ordinary running and special running.
l A back-up power unit is equipped to help maintain the door machine’s ability to run for five hours incase of power failure.
l Installation is very easy; the user just has to embed it underground. The running part can return to the zero point in two directions. The zero position can be set at the original zero point with the controlling system.
l The door control is optional with remote monitoring the sensor.
