3d lazer makine fiber laser marking machine
Jinan XinTian Technology Co., Ltd was established in 2004. It is a professional manufacturer engaged in the research, development, production and service of Diode pumped Laser marking machine, Fiber laser marking machine, CO2 laser marking machine, Pneumatic marking machine, Laser engraving machine, Laser welding machine, Laser cutting machine and Laser trimming machine.
Application & Materials:
This type laser marker suitable for Gold, Silver, Diamond, Sanitary Equipments, Foods Packing, Tobacco Label, Beer label, Drink Label, Medicine Packing, Medical Equipments, Glasses and Clock, Auto Parts,Plastic& Paper Materials, The Electron, Hardware which with high request for depth, smooth,accuracy such as horologe, Mould, bitmap marking etc.
Laser Power: 10W, 20W, 30W, 50W
Technical Parameters:
Laser Source |
Fiber Laser |
Output Power |
50W30W/20w/ 10w |
Wavelength |
1060nm |
Beam Quality |
<2 |
Repeat Frequency |
10khz--- 100khz |
Pulse Energy |
2mJ |
Beam Divergence |
-0.3 to +0.3mrad |
Laser Class |
IV |
Resolution |
18μ |
Repeatablility |
50μ |
Marking Scope |
110mmx 110mm/ 175mmx 175mm (optional) |
Linear Speed |
800 character/ s |
Marking Linear Speed |
≤12,000mm/s |
Marking Depth |
Max. 1.0- 1.5mm (hard steel) |
Min. Line Width |
0.012mm |
Min. Character Size |
0.15mm |
Repeat Accuracy |
±0.003mm |
Input Power |
0.5kw |
Electrical Source |
220v/50hz or 60hz |
Warranty
1. 2 years warranty for this fiber laser marking machine
2. Our customer will be fully trained for the operation and maintaining technology after the order confirmed.
3. Skilled engineer will help customer to solve the problem by MSN, SKYPE,QQ etc in time when problem happened.
Quality control
1. Skilled and strict Quality Inspection Team is available during the material purchasing and production procedure.
2. All finished machine we shipped out are 100% strictly tested by our QC department and engineering department.
Payment:
T/T (Bank transfer), Western Union, Papal, Escrow etc. Basically, the payment ways can be decided by our customer.
Delivery time
It's up to the real quantity. Basically, we have enough inventory, so, less than 5 sets machine can be prepared within 3-5 working .
Package
1. It is well packed with export wooden case.
2. The package size is: 380*610*720mm
OEM Service
1. Customized and OEM orders are welcome due to our aboundant experiences.
2. All the OEM services are free, customer only need to provide us with your logo drawing, function requirements, colors etc.
3. No MOQ required.
Privacy:
None of your personally identifiable information ( such as your name , address , email address ,bank info ,etc ) will be disclosed or shared with any third parties.
Contact:
All of your inquiries or questions or helps will be answered within 12 hours, even in holiday. Also, please feel free to call us if you have any emergency questions.
Cherry 008615820019181
Email:lasermachine01at
