20w 30w 50w xt laser fiber engraver
Standard Model :
Including Control Box ,Lifting worktabke with laser head ,Laptop .This machine is very compact and can put on the desk for marking works.package size : 850x480x850mm ,Gross weight: 95 kgs . Transporaton : By Sea or Airline .
Features:
1.Marking high precision spare parts , such as Gold, Silver, Jewelry, Electronic spare parts etc.
2. High speed marking speed and perfect marking effects.
3.Working time : 200,000 hours(USA model) don't need change any consumptive materials .4.CE certificates 5.Compact designing .
6.Min marking letter : 0.15mm 7.Max .Marking depth :1.5-2.0mm (hard steel )
Delivery Time:1 week/ Transportation: BY SEA ,AIRLINE
Application & Materials:
This type laser marker suitable for Gold, Silver, Diamond, Sanitary Equipments, Foods Packing, Tobacco Label, Beer label, Drink Label, Medicine Packing, Medical Equipments, Glasses and Clock, Auto Parts,Plastic& Paper Materials, The Electron, Hardware which with high request for depth, smooth,accuracy such as horologe, Mould, bitmap marking etc.
Laser Power: 10W, 20W, 30W, 50W
Technical Parameters:
Laser Source |
Fiber Laser |
Output Power |
50W30W/20w/ 10w |
Wavelength |
1060nm |
Beam Quality |
<2 |
Repeat Frequency |
10khz--- 100khz |
Pulse Energy |
2mJ |
Beam Divergence |
-0.3 to +0.3mrad |
Laser Class |
IV |
Resolution |
18μ |
Repeatablility |
50μ |
Marking Scope |
110mmx 110mm/ 175mmx 175mm (optional) |
Linear Speed |
800 character/ s |
Marking Linear Speed |
≤12,000mm/s |
Marking Depth |
Max. 1.0- 1.5mm (hard steel) |
Min. Line Width |
0.012mm |
Min. Character Size |
0.15mm |
Repeat Accuracy |
±0.003mm |
Input Power |
0.5kw |
Electrical Source |
220v/50hz or 60hz |
Jinan XinTian Technology Co., Ltd was established in 2004. It is a professional manufacturer engaged in the research, development, production and service of Diode pumped Laser marking machine, Fiber laser marking machine, CO2 laser marking machine, Pneumatic marking machine, Laser engraving machine, Laser welding machine, Laser cutting machine and Laser trimming machine.
