Home > Products > Fiber Laser Marking Machine > fiber laser marking machine link
fiber laser marking machine link
- 500 Set / Sets per Month
- Qingdao
- T/T Credit Card
Product Details
Condition: | New | Laser Type: | Fiber Laser | CNC or Not: | Yes |
Cooling Mode: | Air Cooling | Control Software: | EZCAD | Graphic Format Supported: | AI, BMP, DST, DWG, DXF, DXP |
Working Accuracy: | 0.01mm | Place of Origin: | Shandong, China | Brand Name: | XT LASER |
Model Number: | XTL-F30 | Power(W): | 30W | Certification: | CE, ISO, Other, CE, ISO, FDA BV |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
wooden case for bird ring laser engraving machine for birds
Product Description
bird ring laser engraving machine for birds
Standard Model :
Including Control Box ,Lifting worktabke with laser head ,Laptop .This machine is very compact and can put on the desk for marking works.package size : 850x480x850mm ,Gross weight: 95 kgs . Transporaton : By Sea or Airline .
Features:
1.Marking high precision spare parts , such as Gold, Silver, Jewelry, Electronic spare parts etc.
2. High speed marking speed and perfect marking effects.
3.Working time : 200,000 hours(USA model) don't need change any consumptive materials .4.CE certificates 5.Compact designing .
6.Min marking letter : 0.15mm 7.Max .Marking depth :1.5-2.0mm (hard steel )
Delivery Time:1 week/ Transportation: BY SEA ,AIRLINE
Application & Materials:
This type laser marker suitable for Gold, Silver, Diamond, Sanitary Equipments, Foods Packing, Tobacco Label, Beer label, Drink Label, Medicine Packing, Medical Equipments, Glasses and Clock, Auto Parts,Plastic& Paper Materials, The Electron, Hardware which with high request for depth, smooth,accuracy such as horologe, Mould, bitmap marking etc.
Laser Power: 10W, 20W, 30W, 50W
Technical Parameters:
Laser Source | Fiber Laser |
Output Power | 50W30W/20w/ 10w |
Wavelength | 1060nm |
Beam Quality | <2 |
Repeat Frequency | 10khz--- 100khz |
Pulse Energy | 2mJ |
Beam Divergence | -0.3 to +0.3mrad |
Laser Class | IV |
Resolution | 18μ |
Repeatablility | 50μ |
Marking Scope | 110mmx 110mm/ 175mmx 175mm (optional) |
Linear Speed | 800 character/ s |
Marking Linear Speed | ≤12,000mm/s |
Marking Depth | Max. 1.0- 1.5mm (hard steel) |
Min. Line Width | 0.012mm |
Min. Character Size | 0.15mm |
Repeat Accuracy | ±0.003mm |
Input Power | 0.5kw |
Electrical Source | 220v/50hz or 60hz |
Warranty
1. 2 years warranty for this fiber laser marking machine
2. Our customer will be fully trained for the operation and maintaining technology after the order confirmed.
3. Skilled engineer will help customer to solve the problem by MSN, SKYPE,QQ etc in time when problem happened.
Quality control
1. Skilled and strict Quality Inspection Team is available during the material purchasing and production procedure.
2. All finished machine we shipped out are 100% strictly tested by our QC department and engineering department.
Payment:
T/T (Bank transfer), Western Union, Papal, Escrow etc. Basically, the payment ways can be decided by our customer.
Delivery time
It's up to the real quantity. Basically, we have enough inventory, so, less than 5 sets machine can be prepared within 3-5 working .
Package
1. It is well packed with export wooden case.
2. The package size is: 380*610*720mm
OEM Service
1. Customized and OEM orders are welcome due to our aboundant experiences.
2. All the OEM services are free, customer only need to provide us with your logo drawing, function requirements, colors etc.
3. No MOQ required.
Privacy:
None of your personally identifiable information ( such as your name , address , email address ,bank info ,etc ) will be disclosed or shared with any third parties.
Contact:
All of your inquiries or questions or helps will be answered within 12 hours, even in holiday. Also, please feel free to call us if you have any emergency questions.
Cherry 008615820019181
Email:lasermachine01at
Q: Are you a factory or trading company?
We are a manufacturer.
Q: Where are you located? How can we visit you?
1. We locates in Jinan of Shandong, in the north of China.
2 hours flight from Guangzhou(Canton)
Q: How can I confirm if your fiber laser marking machine my needs?
1) You can send us some samples so that we can make a demo video for you.
2) Please contact our sales engineers for confirmaton via sending an inquiry.
Q: What's your payment terms? MOQ?
We accpet T/T(bank transfer), L/C, Paypal, ESCOW, West union etc. Usually we need 30% as deposit, balance paid before shipment. MOQ 1 set.
Q: If I bought a machine, how could you make it safe while shipping.
We have a professtional package suitable for oversea transpotation. Machine will be fixed well in the case.
Q: What's your quality control system?
All machines will be tested after finished. We have QC department response for this job. And we already got ISO 9001 & CE approved.
Q: What's your after-sales service?
1) Warranty two year
2) Engineers available service machinery overseas
3) Full operator training
Q: If I don't know how to use the machine, can you teach me?
1) There is a DVD disc including machine user manual and software user manual c/w machine.
2) Online (skype & phone)
3) Remote desktop software (Teamviewer)
4) Demo Video
Company Profile
Jinan Xintian Technology Co.,Ltd was established in 2004,it is a professional manufacturer engaged in the research, development, production and service of laser marking machine,fiber laser marking machine.pneumatic marking machine,laser engraving machine,laser welding machine, laser cutting machine and laser trimming machine.
We possess high efficient cooperated technology and sevice team, high coordinated producing and service network. Our company strictly according to ISO9001:2008 international quality management system elements of conduct production,process inspection,incoming inspection,various links quality,Pay attention to produce aftersales quality feedback and continuous imporvement principle,ensure products performance and stable quality
Our company will continue its efforts in every colleague support,in other fields to make greater achievements.Jinan Xintian Technology Co.,Ltd also met with more excellent products and more satisfied with the cost performance of more satisfactory service to acknowledge old and new customers for supports love.
