Specifications
Coal Power Burner For Asphalt Plant1. high flame temperature, saving energy, burning full.
2.Can be used for Aspahlt Plant .
Coal firing burner /Coal Power Burner/coal pulverizer burner For Asphalt plant
MF Series rotating pulverized coal burner is a new generation of application of asphalt heating equipment, the product has the following characteristics:
With new structure, change the traditional mechanism of burner, the combustion chamber adopts rotating method to solve
traditional burner easy slagging, such problems as incomplete combustion.
1. high flame temperature, saving energy, burning full.
2. adopts the exclusive ingredients of firebrick of high performance, prolong service life.
3. can be continuous production, need not everyday slag removal.
Working principle of the coal burner:
Raw material is below 25 mm crushed by the coal machine, after through the metal hose nozzle spray into the combustion
chamber hostby oil gun fire burning. And blower combustion chamber via the host back cover annular rotating duct blower,
the wind go round stickinside air entrainment high temperature smoke strongly mixing with pulverized coal combustion,
the flow of high temperature flame by spray into the drying tube heating sand, stone of the crater.
the following is a series of burner configuration parameter table
|
Combustor |
Coal Pulverizer |
Power |
Consumption(kg//h) |
Application for asphalt Plant(T/h) |
MF1000 |
SM80 |
MF80 |
47.5KW |
900 |
60-80
|
MF1500 |
SM120 |
MF120 |
73KW |
1200 |
80-100
|
MF2000 |
SM160 |
MF80×2 |
93.5KW |
1600 |
120-160
|
MF3000 |
SM240 |
MF120×2 |
155KW |
2400 |
200-240
|
MF4000 |
SM320 |
MF120×3 |
185KW |
3200 |
260-320
|
construction site of the pulverized coal burner:
if you want to know more in formation, please contact me:
