36"-42" Pipe Cold Cutting And Beveling Machine

36"-42" Pipe Cold Cutting And Beveling Machine thumbnail-1
36"-42" Pipe Cold Cutting And Beveling Machine photo-1
US$ 20,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
Nodha
Contact Supplier Request Quote Chat Now
Nodha Industrial Technology Wuxi Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name Nodha
Model Number ODH-1066
Voltage 380-415V
Rated Power 2.2kw
Dimension(L*W*H) 1385*1385*320mm
Weight 342kgs
Certification CE ISO
Warranty One Year
After-sales Service Provided Engineers available to service machinery overseas

Pipe Cutting and beveling Machine:





The series machine is ideal for all types of pipe cutting, beveling and end preparation. The split frame design allows the machine to split in half at the frame and mount around the OD of the in-line pipe or fittings for strong, stable clamping. The equipment performs precision in-line cut or simultaneous cut/bevel, single point, counterbore and flange facing operations, as well as weld end preparation on open ended pipe, Ranging from 3/4” to 56 inches O.D.(DN20-1400), on most wall thicknesses and material.



36"-42" Pipe Cold Cutting And Beveling Machine

  • Cold Cutting and Beveling improves safety
  • Cutting and Beveling simultaneous
  • Split Frame: easy mounted on pipeline
  • Tools feed automatically
  • Fast, Precision, On-site Beveling
  • Minimal Axial and Radial clearance
  • Light weight and compact design
  • Easy set-up & Operation
  • Electric or Pneumatic or Hydraulic driven
  • Machining heavy-wall pipe from 3/4” up to 56”

36"-42" Pipe Cold Cutting And Beveling Machine

  • Oil & Gas
  • Power Plant
  • Chemical Plant
  • Nuclear Power
  • Process Plant & Fabrication
  • Ship Building & Repair

36"-42" Pipe Cold Cutting And Beveling Machine

  • Drive Options: Pneumatic, Hydraulic, and Electric
  • Air requirement: 1500L-3000L Per minute 0.6/0.7Mpa
  • Hydraulic requirement: 2-60L per minute 12.5Mpa
  • Electric requirement:220-240V 1PH 50/60HZ
  • Feed mode: Star wheel, automatically
  • Feed rate: Fixed 0.08mm per circle
  • Packaging: Plywood case

36"-42" Pipe Cold Cutting And Beveling Machine



Model

Working Range (OD)

d (mm)

h (mm)

L (mm)

Inch

mm

89

3/4”-3”

25-89

94

137

160

159

2”-5”

50-159

170

215

178

168

2”-6”

50-168

185

225

178

230

3”-8”

80-230

236

253

178

275

5”-10”

125-275

283

277

178

305

6”-10”

150-305

316

290

178

325

6”-12”

168-325

334

303

178

377

8”-14”

219-377

386

330

178

426

10”-16”

273-426

438

357

180

457

12”-18”

300-457

469

373

180

508

14”-20”

355-508

518

399

190

560

16”-22”

400-560

570

424

190

610

18”-24”

457-610

618

448

190

660

20”-26”

508-660

670

474

190

715

22”-28”

550-715

719

519

190

762

24”-30”

600-762

770

539

190

830

26”-32”

660-813

830

567

192

914

30”-36”

762-914

924

613

212

1066

36”-42”

914-1066

1077

741

212

1230

42”-48”

1066-1230

1248

777

212

1430

50”-56”

1230-1430

1438

877

220



Suggest: size 1066 and above size select and use hydraulic type





36"-42" Pipe Cold Cutting And Beveling Machine



Before you place order to us, please let us know the following information:

  • Choose the right Model

  • Confirm your electric power supply ( Voltage, frequency and phase)

  • Confirm the beveling angel required

  • Confirm the welding joint required (U, V, Double V or Compound preparation)

  • Advise your pipe material ( Carbon steel, stainless steel or others)

  • Other special demands about machine

  • The spare parts needed

  • If the pipe wall thickness more than 30mm, inform us in advance (Important)
