Help CenterNODHA Alumininm Body Pipe Cold Cutting and Beveling Machine 32" Pipeline Maintain
Related Products
Pipe Cold Cutting and beveling Machine
The split frame design of the equipment allows the machine to separate and mount around the OD of the in-line pipe or fittings for strong, stable clamping. The equipment performs precision in-line cut or simultaneous cut/bevel operations, as well as weld end preparation on open ended pipe
Cold Cutting and Beveling improves safety
Cutting and Beveling simultaneous
Split Frame: easy mounted on pipeline
Tools feed automatically
Fast, Precision, On-site Beveling
Minimal Axial and Radial clearance
Light weight and compact design
Easy set-up & Operation
Electric or Pneumatic or Hydraulic driven
Machining heavy-wall pipe from 3/4” up to 48”
Oil & Gas
Power Plant
Chemical Plant
Nuclear Power
Process Plant & Fabrication
Ship Building & Repair
Model |
Working Range (ID-OD) |
|
Inch |
mm |
|
89 |
3/4”-3” |
25-89 |
159 |
2”-5” |
50-159 |
168 |
2”-6” |
50-168 |
230 |
3”-8” |
80-230 |
275 |
5”-10” |
125-275 |
305 |
6”-10” |
150-305 |
325 |
6”-12” |
168-325 |
377 |
8”-14” |
219-377 |
426 |
10”-16” |
273-426 |
457 |
12”-18” |
300-457 |
508 |
14”-20” |
355-508 |
560 |
16”-22” |
400-560 |
610 |
18”-24” |
457-610 |
660 |
20”-26” |
508-660 |
715 |
22”-28” |
550-715 |
762 |
24”-30” |
600-762 |
830 |
26”-32” |
660-813 |
914 |
30”-36” |
762-914 |
1066 |
36”-42” |
914-1066 |
1230 |
42”-48” |
1066-1230 |
Before you place order to us, please let us know the following information:
- Choose the right Model
- Confirm your electric power supply ( Voltage, frequency and phase)
- Confirm the beveling angel required
- Confirm the welding joint required (U, V, Double V or Compound preparation)
- Advise your pipe material ( Carbon steel, stainless steel or others)
- Other special demands about machine
- The spare parts needed
- If the pipe wall thickness more than 30mm, inform us in advance (Important)
