Specifications
bag on valve aerosol filling machinePLC control
filling speed:20-25cans/min
This machine is specifically designed for bag on vavle aerosol products filling, it is PLC controlled with a frendly touch screen interface, comparing with previous pneumatic control one, this version is improved a lot in efficiency, intelligence, parameters setting, process supvision and trouble shooting. There are two heads seated on the working table, the first head combines the function of vacuumizing, prppellant filling and criimping, more economic propellants are optional for customer such as N2, Co2, Ar or even comperssed air. The second head is aiming to charge the liquid material into bag through the valve, since material is insolated into bag and will not touch propellant, thus this machine is widely used for pharmaceutical, food, cosmetic and other bag on valve products manufacturing. And there is no any limitration about water base, oil base or alcohol based liquid.
Filling capacity |
0-250ml |
Filling speed |
1200-1500cans/hour |
Filling tolerance |
≤±1% |
Compressed air consumption |
0.8m3/min at pressure 0.7MPa |
Machine size in mm |
900*550*1580 |
Net weight in Kg |
220 |
