Help CenterAutomatic Sliding Door Operator
Related Products
Specifications
1.automatic sliding door operator2.sliding door operator
3.10 Years Experience
4.Remote Control
5.Certificate:ISO9001,CE
automatic sliding door operator
product specification
Model |
SD150 |
|
Door range |
Single-leaf door |
Double-leaf door |
Door leaf weight |
150kg*1 |
150kg*2 |
Door width |
700~1500mm |
700~1300mm |
Opening rate |
100~550mm/s (Adjustable) |
|
Opening hours |
0~9seconds |
|
Motor |
DC24V Brushless DC Servo Motor |
|
Reducer |
Worm as a whole sealed structure |
|
Supply voltage |
Input AC180-250V; 50-60Hz |
|
Ambient temperature |
-20~50°C |
|
|
Power failure back-up system |
Selective accessory: DC24V7AH* Batteries |
|
|
Adaptive access control system |
Selective accessory:credit card machine,induction cardmachine,remote control motor lock,access control network host. |
|
Optional accessories |
Selective accessories:Security light,remote hand-voltage switchgear |
|
Specification |
nology Drive equipment with low noise, easy installation.Intelligent control system with variable adjustable parameters.Adpot german high tech, passed CE and ISO 9001-2000.Using brushless DC Motor, 2 years warranty. 2.advanced motor Advanced brushless motor and worm wheel reducer are integrated,with lower consumption,energy saving, high efficiency, great torque and long life. 3.automatic door functions The control device will be alarmed,when someone force to open the door.The door can be opened or closed all the time.the door can be opened or closed or half opened by remote control, password swipe card reader,microwave sensor.body sensor, switch button. 4.safety The door can be opened or closed all the time.The control device will be alarmed,when someone force to open the door.The magnetic lock can be installed, make more secure.Safety beam protects the guest from bumping the door, safety and reliable.optional backup battery can ensure the normal operation when the power failure. 5. Self-monitoring The microprocessor has an integral self-monitoring device which detects any interference or faulty signals in door operation and takes necessary measures to ensure a safe operation.
|
|
