automatic sliding door operators (with alarm)

Model

SD100

SD150

SD200

SD280

Door range

Single-leaf door

Double-leaf door

Single-leaf door

Double-leaf door

Single-leaf door

Double-leaf door

Single-leaf door

Double-leaf door

Door leaf weight

100kg*1

90kg*2

150kg*1

135kg*2

130kg*1

110kg*2

180kg*1

150kg*2

Door width

700~1300mm

700~1100mm

700~1500mm

700~1300mm

700~1300mm

700~1100mm

700~1500mm

700~1300mm

Opening rate

100~550mm/s (Adjustable)

Opening hours

0~9seconds

Motor

DC24V Brushless DC Servo Motor

Reducer

Worm as a whole sealed structure

Supply voltage

Input AC180-250V; 50-60Hz

Ambient temperature

-20~50°C

Power failure

back-up system

Selective accessory: DC24V7AH* Batteries

Adaptive access

control system

Selective accessory:credit card machine,induction cardmachine,remote control motor lock,access control network host.

Optional accessories

Selective accessories:Security light,remote hand-voltage switchgear

Features:

Adpot german high tech, passed CE and ISO 9001-2000.Using brushless DC Motor, 2 years warranty.

*Intelligent control system with variable adjustable parameters.

*Drive equipment with low noise, easy installation.

*Advanced brushless motor and worm wheel reducer are integrated,with lower consumption,energy saving, high efficiency, great torque and long life.

*the door can be opened or closed or half opened by remote control, password swipe card reader,microwave sensor.body sensor, switch button.

*The door can be opened or closed all the time.

* The control device will be alarmed,when someone force to open the door.

* The magnetic lock can be installed, make more secure.

*Safety beam protects the guest from bumping the door, safety and reliable.

*optional backup battery can ensure the normal operation when the power failure
