Help CenterParallel Beam Load Cell
Related Products
Specifications
Load cell1.Single-point, Parallel beam,
2.Aluminium load cell;
3.For electronic scale ,floor scale and other equipment
Load cell; Single point,parallel Beam, Aluminum load cell;
Widely used for electronic top scales ,floor scale and other weighing equipment.
Capacity (KG): 60100,150,200,250,300
Hermetically sealed with glue to IP65
Surface anodized and anti-corrosion, integral structure and easy installation.
Outline size;150(L)x45(W)x40(H)mm
Recommended platform size:400x400mm
Specifications:
Accuracy grade:C2/C3
Comprehensive error (%F.S) : ±0.02/ ±0.017
Sensitivity (mv/v) : 2.0±0.2
Creep (%F.S/30min) : ±0.02/ ±0.017
Zero output (%F.S) : ±1.0
Input Resistance (Ω): 405±10
Output Resistance (Ω): 350±3
Insulation resistance (MΩ) : ≥5000(100VDC)
Temperature Effect on Zero (%F.S/10): ±0.03 / ±0.017
Temperature Effect on Span (%F.S/10): ±0.02 / ±0.014
Temperature compensation range (°C ) : -10~+40
Operating temperature (°C ) : -20~+60
Excitation voltage (V) : 9~12(DC)
Safe overload (%F.S) : 120
Limit overload (%F.S) : 150
Protection Grade: IP65
Installation size diagram:
Wire connecting method:
red input +
while output -
black input -
green output +
Power diagram:
