Specifications
LED dual output switching power supply D-30-BCE approval, with better radiating effect
high quality, best serveice
LED dual output switching power supply D-30-B
- Dual output switch power supply
- Competitived price and high reliability
- 105oC Output capacitor
- AC input power suitable for the world
- High efficiency and low operation temperature
- Soft-start current can reduce the AC input impact effeciticly
- With short-circuit and overload protection
- Compact size, light weight
- 100% full-load burn-in test
- Installed with EMI filter, minimum wave
| Model | D-30A | D-30B | ||
| CH1 | CH2 | CH1 | CH2 | |
| DC output voltage | 5V | 12V | 5V | 24V |
| Output voltage range(Note:2) | ±2% | +3,-7%% | ±2% | +3,-5% |
| Rated output current | 4A | 1A | 2.2A | 1A |
| Output current range | 0.5-4A | 0.1-1A | 0.5-4A | 0.1-1A |
| Wave and noise(Note:3) | 50mVp-p | 100mVp-p | 50mVp-p | 100mVp-p |
| Inlet stability(Note:4) | ±0.5% | ±1% | ±0.5% | ±1% |
| Load stability(Note:5) | ±0.5% | ±4% | ±0.5% | ±4% |
| DC output power | 32W | 35W | ||
| Efficiency | 72% | 74% | ||
| Adjustable range for DC voltage | CH1; +10, -5% | CH1; +10, -5% | ||
| Input current | 0.8A/115V0.45A/230V | |||
| AC inrush current | Cold-start current 18A/115V 36A | |||
| Leakage current | <0.5mA/240VAC | |||
| Overload protection | 105%~150% Type: pulsing hiccup shutdown Reset: auto recovery | |||
| Temperature coefficient | ±0.03%/°c(0~50°c)ON+5V | |||
| Setup, rise , hold up time | 200ms,50ms, 30ms | |||
| Vibration | 10~500Hz, 2G 10min,/1cycle, Period for 60min, Each axes | |||
| Withstand voltage | Input and output internal: Input and encolsur: 1.5KvAC, Output and enclosure: 0.5KvAC | |||
| Isolation resistance | Input and output internal: Input and enclosure, Output and enclosure:500VDC/100MΩ | |||
| Working temperature and humidity | -10°c~+60°c(Refer to output derating curve), 20%~90%RH | |||
| Overall dimension | 129×98×38mm | |||
| Weight | 0.4Kgs | |||
| Safety standards | Meet UL requirement (Not apply for the mark) | |||
| EMC standards | Meet FCC PART 15 J Conduction class A | |||
|
Note: 1. The testing condition for the paramenter above is: 230VAC input, rated load, 25°c 70% RH. Temperatuer. 2. Error: include the setting error, line stability and load stability.(Note:5). 3. Wave test: adopting "A12" double wire for 20MHz, and 0.1UF&47UF capacitor short-circuit for interrupting. 4. Inler woltage stability test: when is over load, the lowest voltage of inlet is up to the highest voltage. 5. Load stability test: The load is from 0% to 100%. 6. Total output canba maxinum Current, total load can not exceed the maxium output power. | ||||
