DS-30 Agricultural Blast Sprayer Dry Fog Water Spray Cooling System

DS-30 Agricultural Blast Sprayer Dry Fog Water Spray Cooling System photo-1
DS-30 Agricultural Blast Sprayer Dry Fog Water Spray Cooling System photo-2
DS-30 Agricultural Blast Sprayer Dry Fog Water Spray Cooling System photo-3
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
FengHua
Model Number:
DS-30
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Guangdong
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name FengHua
Model Number DS-30
Sprayer Type Other
After-sales Service Provided Engineers available to service machinery overseas

 DS-30 agricultural blast sprayer dry fog water spray cooling systemDS-30 agricultural blast sprayer dry fog water spray cooling system

  !!! SAFETY FIRST !!! BEWARE OF IMITATIONS !!!

DS-30 agricultural blast sprayer dry fog water spray cooling system









Product advantage & Feature :

1. Professional manufacturer with over 20 years' experience, high quality, best service and competitive price, offer multiple choices of product to meet different requirements.
2.Strong capability, high & far throw range, wide coverage area, achieve precise volume spraying, high efficiency and spray speed.
3. Micro fog droplet, form a wet mist touching the floating dust, high speed knock down the dust.
4. Flexible power: three-phase 380V and diesel generator power supply optional
5. Flexible installation, fixed on the concrete platform or diesel generator-powered vehicles optional.
6. Flexible, safe & reliable to use. Remove control & manual control operation. Easily adjust the spray angle of horizontal rotation.
7. Compare to tank car, water consumption save 70% ~80%, wide coverage area.







Scope of Application:



Forestry



Applicable to various vehicles mounted: light truck, tractor, and etc.
Simple assembly & disassembly.
Manual control and remote control in driving cab, safe & convenient operation.
High power, big air quantity, wide coverage area, uniform fog droplet.
The gas-liquid mixture can turn the leaves of plants effectively, so that the pesticide can be sprayed to both sides of theleaves evenly.
For the strong penetration and liquid adhesion, it can effectively save the pesticide and reduce the pollution.
High efficiency, wide application, spray fast speed and spraying with vehicle running.




Agriculture



1.The sprayer can used for pest control in agriculture, orchard, garden areas,farmland, forest, road greening, grassland, pasture ,etc.
2.Environmental protection industry, mining, coal yard, docks, steelworks and other dust relatively large construction site for dust control.
3. Epidemic Prevention in large area such as City streets, Stations, Ports, Public Places, Landfills, etc.







Working Theory







Technical Specification



Type

DS-30

Throw

30m*no wind

Volume Flow

9-18L/min

Water Pressure

1.5-3.0Mpa

Fog Droplet Size

50-150um (adjustable)

Pitching Angle

-10~90°

Horizontal Rotation Angle

180° Manual

Overall Dimensions(L*W*H)

L130*W115*H148 (cm)

Sprayer Tank

1000L,2000L....(OPTIONAL)







 DS-30 agricultural blast sprayer dry fog water spray cooling system
